iBox/iBox Kit
Installation and Maintenance Guide
GE Grid Solutions
158
994-0047-5.10-4 GE Information
DCA DPA
Source
Data
Type
MODBUS DCA
Register
Address
Point Description
COM1 COM2
DNP DPA
Point
MODBUS DPA
Point Address
DNP TCP/IP
DPA Point
MODBUS DCA
(IBOX
-
DCA and IBOX
-DCL)
AI
0 ADAM-4017 AI CH: 00 N/A N/A N/A
1 ADAM-4017 AI CH: 01 N/A N/A N/A
2 ADAM-4017 AI CH: 02 N/A N/A N/A
3 ADAM-4017 AI CH: 03 N/A N/A N/A
4 ADAM-4017 AI CH: 04 N/A N/A N/A
5 ADAM-4017 AI CH: 05 N/A N/A N/A
6 ADAM-4017 AI CH: 06 N/A N/A N/A
7 ADAM-4017 AI CH: 07 N/A N/A N/A
Calculator DTA
AI
N/A Scaled Analog Input #1 0 1 0
N/A Scaled Analog Input #2 1 2 1
N/A Scaled Analog Input #3 2 3 2
N/A Scaled Analog Input #4 3 4 3
N/A Scaled Analog Input #5 4 5 4
N/A Scaled Analog Input #6 5 6 5
N/A Scaled Analog Input #7 6 7 6
N/A Scaled Analog Input #8 7 8 7
MODBUS DCA
(IBOX-ACA and IBOX-ACL)
AI
278 VOLT PHASE A-N INST 0 1 0
279 VOLT PHASE B-N INST 1 2 1
280 VOLT PHASE C-N INST 2 3 2
281 VOLT PHASE A-B INST 3 4 3
282 VOLT PHASE B-C INST 4 5 4
283 VOLT PHASE C-A INST 5 6 5
284 AMP PHASE A INST 6 7 6
285 AMP PHASE B INST 7 8 7
286 AMP PHASE C INST 8 9 8
287 AMP NEUTRAL INST 9 10 9
288 WATT INST 10 11 10
289 VAR INST 11 12 11
290 VA INST 12 13 12
291 PF INST 13 14 13
292 FREQ INST 14 15 14
293 WATT PHASE A INST 15 16 15
