GE iBox User Manual

GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
159
DCA DPA
Source
Data
Type
MODBUS DCA
Register
Address
Point Description
COM1 COM2
DNP DPA
Point
MODBUS DPA
Point Address
DNP TCP/IP
DPA Point
MODBUS DCA
(IBOX-ACA and IBOX-ACL) continued
AI
294 WATT PHASE B INST 16 17 16
295 WATT PHASE C INST 17 18 17
296 VAR PHASE A INST 18 19 18
297 VAR PHASE B INST 19 20 19
298 VAR PHASE C INST 20 21 20
299 VA PHASE A INST 21 22 21
300 VA PHASE B INST 22 23 22
301 VA PHASE C INST 23 24 23
302 PF PHASE A INST 24 25 24
303 PF PHASE B INST 25 26 25
304 PF PHASE C INST 26 27 26
317 VOLT PHASE A-N AVG 27 28 27
318 VOLT PHASE B-N AVG 28 29 28
319 VOLT PHASE C-N AVG 29 30 29
320 VOLT PHASE A-B AVG 30 31 30
321 VOLT PHASE B-C AVG 31 32 31
322 VOLT PHASE C-A AVG 32 33 32
323 AMP PHASE A AVG 33 34 33
324 AMP PHASE B AVG 34 35 34
325 AMP PHASE C AVG 35 36 35
326 AMP NEUTRAL AVG 36 37 36
327 WATT AVG 37 38 37
328 VAR AVG 38 39 38
329 VA AVG 39 40 39
330 PF AVG 40 41 40
331 FREQ AVG 41 42 41
332 WATT PHASE A AVG 42 43 42
333 WATT PHASE B AVG 43 44 43
334 WATT PHASE C AVG 44 45 44
335 VAR PHASE A AVG 45 46 45
336 VAR PHASE B AVG 46 47 46
337 VAR PHASE C AVG 47 48 47
