GE Grid Solutions
iBox/iBox Kit
Installation and Maintenance Guide
GE Information
994-0047-5.10-4
System Software, continued
68K Monitor
The iBox 68K Monitor, available through WESMAINT, is a diagnostic tool used to
access system-level functions.
The iBox 68K Monitor is resident in both BootROM and flash memory.
When the Monitor is operated from BootROM, the following prompt appears:
D25S>. This mode is accessed only while the iBox is in a maintenance state, since
forcing an iBox into this mode terminates all running applications.
When the Monitor is operated from flash, the following prompt appears: D25A>.
This is the normal mode of operation, and it can be accessed via WESMAINT at any
time without disrupting unit operation.
Using the 68K Monitor requires detailed knowledge of the iBox architecture and
functionality. Refer to the 68K Monitor User’s Guide (SWM0023) for complete
instructions about command usage and availability.
