iBox/iBox Kit
Installation and Maintenance Guide
GE Grid Solutions
994-0047-5.10-4 GE Information
Battery Replacement
Battery
Location
The battery is located in position BT1 on the main board. To find the battery, remove
the iBox top cover, and look to the bottom center-right of the main board, close to
the column of relays.
Battery Type
The iBox uses a 3 V, BR2/3A, lithium battery, GE part number 980-0026.
Procedure
To replace the battery:
Step Action
1
Remove power to the iBox.
2
Remove the top cover.
3
Remove the battery by removing the holder clip.
4
Replace the battery with a GE battery, part number 980-0026. Check that
battery has been inserted correctly by verifying the polarity markings.
5
Snap the battery holder clip back into place.
6
Replace the cover.
7
Reconnect the power.
