Runtime and Startup Errors, continued
iBox Trouble-
shooting Tips
Symptom Possible Causes Suggestions
Active Operations
Aborted
Controls Jumper is in the Local
position (JP2 is removed).
Move the Controls Jumper
to the Remote position
(Install JP2).
Active Requests
Aborted
The iBox Plant I/O Subsystem
monitoring detects a conflict
between desired and actual
coil status (a coil is not
energized when it should be).
Verify coil status.
Digital Output
Requests Rejected
Controls Jumper is in the Local
position (JP2 is removed).
The iBox Plant I/O Subsystem
monitoring detects a conflict
between desired and actual
coil status (a coil is not
energized when it should be).
Move the Controls Jumper
to the Remote position
(Install JP2).
Verify coil status.
Queued Requests
Cleared
Controls Jumper is in the Local
position.
The iBox Plant I/O Subsystem
monitoring detects a conflict
between desired and actual
coil status (a coil is not
energized when it should be).
Move the Controls Jumper
to the Remote position
Verify coil status
System Hangs Watchdog failure.
Attempt Reboot, clear CCU
error logs
Plant I/O Watchdog
Failure
Plant I/O Subsystem integrity is
faulty.
Remove and restore power
to the iBox
Digital output Points
are Disabled
The Local/Remote Jumper is in
the Local position (JP2 is
removed).
Move the Local/Remote
Jumper to the Remote
position (Install JP2).
Communication
Watch Dog Failure
Internal system monitors
detect serious errors.
Attempt Reboot, clear CCU
error logs.
Coil Status Check
The iBox Plant I/O Subsystem
monitoring detects a conflict
between desired and actual
coil status.
Verify coil status.
Digital output coils are
not in the state
requested by the
software
Plant I/O Sub failure
Hardware Watchdog.
Check Control Voltage
source fuses. Check voltage.
Force from WESMAINT
Digital Output Failure
Control Voltage Not Available,
Coil Status Check, or Hardware
Watchdog error condition.
Check Control Voltage
source fuses. Check voltage.
Force from WESMAINT.
Continued on next page
