GE JK5000 Technical Service Guide

27
GE Title or job number
11/26/2013
SERVICE MODE T012 continued
The loads and associated keys are listed below:
BAKE –Energize the Bake and the DLB relays for the corresponding cavity.
BROIL –Energize the Broil and the DLB relays for the corresponding cavity.
If a key is pressed while another load is already on, the control shall first turn off the first load and then
activate the new load (i.e. User presses Bake and within 5 seconds the User presses Broil, the control shall turn
on the Bake and DLB from when the user fist presses Bake until the user presses Broil, then the control shall
turn off the Bake relay and turn on the Broil relay and hold the Broil element on until 10 second after the key
has been pressed. So no 2 element loads can be on at the same time.
SELF-CLEAN –Energize the door lock motor and display the door lock status as it would in normal
mode. (NOTE: if the door lock is unlocked, this key press shall lock the door and if the door lock is locked, then
the key press shall unlock, it should not be ruled by the 10 second timer as other keys are.
CONVECTION BAKE – Energize the convection element and the DLB relays. (if used)
#1 or #2 – Energize the convection fan. (if used)
OVEN LIGHT – Energize the oven light(s).
SET CLOCK – Energize the cooling fan relay.
DELAY TIME – Display the software version in the time digits.
START – No response.
TIMER ON/OFF – Light up all LED segments.
LOCK CONTROL – Energize the cooling fan motor (low)*
DIGIT KEYS – Light up in every available 7-segment display the key being pressed (pressing the 7
key would show “777 77:77”). NOTE: The “1” and “2” keys are used for convection fan, and should also display
the digits in the display when applicable.
CLEAR/OFF – Shall reset the control.
