Common features:
Panelized cavities - 4.3 cu. ft. 27” – 5.0 cu. ft. 30” - not
serviceable part
Hinge receivers- built into vertical supports - not serviceable
part
Cavity racks- Conventional ribs built into cavity panels
Ladder racks- Rack supports mounted to side panels
Latch assembly - New design, enables door latch pawl to be
unlatched if unit fails in LOCKED mode. Note: a 7” piece of
brazing solder, bent into “L” shape works very well to access
latch pawl. Be sure to put tape on “tool” to prevent scratching
trim.
