GE JK5000 Technical Service Guide

29
GE Title or job number
11/26/2013
SERVICE MODE MC continued
The loads and associated keys are listed below:
BAKE –Energize the Bake and the DLB relays for the corresponding cavity.
BROIL –Energize the Broil and the DLB relays for the corresponding cavity.
SELF-CLEAN –Energize the door lock motor and display the door lock status as
it would in normal mode. (NOTE: if the door lock is unlocked, this key press shall
lock the door and if the door lock is locked, then the key press shall unlock, it
should not be ruled by the 10 second timer as other keys are)
STEAM CLEAN – Display in the temperature digits the most recent F-code. Each
subsequent press of the Steam Clean key shall display the next most recent
F-code. The Temperature display shall go back to the current RTD temperature
after 10 seconds of no key presses.
Press and holding the STEAM CLEAN button for 3.5 seconds will clear F-codes.
COOK TIME –Calculate and display the CRC checksum in the time digits.
CONVECTION BAKE – Energize the convection element and the DLB relays.
#1 – Energize the convection fan in the CCW direction. NOTE: if the “2” key has
been pressed and the fan spinning in the CW direction, the control will wait at
least 10 seconds before starting to energize the fan in the CCW direction to
prevent welding the relay.
#2 – Energize the convection fan in the CW direction. NOTE: if the “1” key has
been pressed and the fan spinning in the CCW direction, the control will wait
at least 10 seconds before starting to energize the fan in the CW direction to
prevent welding the relay.
OVEN LIGHT – Energize the oven light for the corresponding cavity.
DELAY TIME – Display the software version in the time digits.
PROBE – Display the probe temperature in the temperature display.
SET CLOCK – Energize the cooling fan relay.
