System Setup
3-22 LOGIQ V2/LOGIQ V1 – Basic Service Manual
5610739-100 English Rev.10
Peripherals Installation Instructions
Sony UP-D25MD Printer Installation
Tools
No special tools needed.
Manpower
One person 5 min.
Preparations
1. Unpack the Sony UP-D25MD Printer.
Installation Procedure
1. Place the device in a suitable place.
2. Connect the USB Cable and power cable on the Printer.
3. Connect the power cord in the wall outlet, then turn on the
printer.
4. Connect USB cable to LOGIQ V2/LOGIQ V1 USB port.
Figure 3-6. Color printer Connection
5. Press Utility on the Control Panel.
To Next Page
