General Procedures and Functional Checks
4-14 LOGIQ V3/V5/V5 Expert – Basic Service Manual
5726264-100 English Rev.8
4-2-7-2 Backup System Presets and Configurations
NOTE: Always backup any preset configurations before a software
reload. This ensures that if the presets need to be reloaded,
after the software update, they will be the same ones the
customer was using prior service.
1. Insert a formatted media into the drive.
2. Enter enter Utility-> System-> Backup/Restore.
NOTE: If you are not logged in as GE Service or with administrator
privileges, the Operator Login window is displayed. Log on
with administrator privileges.
3. In the Backup list, select Patient Archive, Report Archive,
User Defined Configuration and Service.
4. In the Media field, select CD/DVD (or USB memory device).
5. Select Backup.
The system performs the backup. As it proceeds, status
information is displayed on the Backup/Restore screen.
Figure 4-7. Backup/Restore Menu
