Equipment Overview
2031504-159D MAC™ 800 2-5
D ECG key Acquires a resting ECG and prints a 10-second report
in Arrhythmia mode.
E Trimpad The arrows move the cursor left, right, up, or down.
The center button moves the focus within a window or
selects the currently active item.
F Rhythm key Prints a continuous, real-time rhythm ECG strip. Press
the Stop key to stop the rhythm strip from printing.
G Stop key Stops the writer from printing.
H Backspace Key Deletes characters.
I Space Key Adds a space between typed characters.
J T9 key Switches between different input methods. For more
information on using the T9 key, refer to the MAC™
800 Operator’s Manual.
Name Description
