GE MAC 800 Service Manual

Parts Lists
2031504-159D MAC™ 800 5-9
MAC 800 Upper Level Assembly Part List
The following table identifies the parts available for the MAC 800
system.
The numbers in the Item column refer to the callouts from the diagrams
found in “MAC 800 Upper Level Assembly Diagrams” on page 5-3.
The numbers in the Part Number column identify the GE Healthcare
part number for orderable parts. Items without part numbers cannot be
purchased independently of a FRU kit.
800 Upper Level Assembly
Item Part Number Item Description
1 M3X8 MACHINE SCREW PHILIPS PAN NI
Included with:
 “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
2 LCD POLY FOAM
Included with “FRU Top Cover Assembly, PN 2039939-001” on page 5-13
3LCD LENS
Included with “FRU Top Cover Assembly, PN 2039939-001” on page 5-13
4 PRINTER BUTTON
Included with “FRU Top Cover Assembly, PN 2039939-001” on page 5-13
5TOP COVER
Included with “FRU Top Cover Assembly, PN 2039939-001” on page 5-13
6 NAMEPLATE 15MM GE LOGO
Included with “FRU Top Cover Assembly, PN 2039939-001” on page 5-13
7 KEYPAD
See “Keypads” on page 5-17
8 2039940-001 MAC800 FRU LCD ASSEMBLY
9 PRINTER DOOR
Included in “FRU Printer Assembly, PN 2039941-001” on page 5-13
10 THERMAL PRINTER HEAD - MAC800
Included with “FRU Printer Assembly, PN 2039941-001” on page 5-13
11 M2X6 MACHINE SCREW PHILIPS PAN
Included with:
 “FRU Printer Assembly, PN 2039941-001” on page 5-13
 “FRU Kits, PN 2039945-001” on page 5-20
12 PRINTER HOLDER
Included with “FRU Printer Assembly, PN 2039941-001” on page 5-13
