GE MAC 800 Service Manual

5-10 MAC™ 800 2031504-159D
Parts Lists
13 PCB MAC800 MAINBOARD
Included with “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
14 REAR PANEL
Included with “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
15 ACQ COVER1
Included with “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
16 ACQ COVER2
Included with “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
17 PATIENT CABLE CONNECTOR HOLDER
Included with “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
18 AN00388 4-40x3/8 SCREW NI
Included with:
 “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
 “FRU Kits, PN 2039945-001” on page 5-20
19 SD CARD HOUSE
Included with “FRU Mainboard Assembly, PN 2039942-001” on page 5-14
20 60W 12V OUTPUT AC-DC MODULE BIG HEATSINK
Included with “FRU Power Supply Assembly, PN 2040052-001” on page 5-14
21 FLAT SCREW M3X12
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
22 CRIMP RING .217
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
24 M4X16 MACHINE SCREW PHILIPS PAN NI
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
25 2039946-001 FUSE 2.0A QUI-BLO 250V 5X20MM
Available as an independent FRU. Also included with “FRU Bottom Cover Assembly, PN
2039943-001” on page 5-15.
26 HEXAGON SCREW1
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
800 Upper Level Assembly (Continued)
Item Part Number Item Description
