Parts Lists
2031504-159D MAC™ 800 5-11
27 HEXAGON SCREW2
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
28 SHIELD PLATE
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
29 CLIP-ON SHIELD COVER
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
30 CABLE FOR MAINBOARD
Included with:
“FRU Power Supply Assembly, PN 2040052-001” on page 5-14
“FRU Kits, PN 2039945-001” on page 5-20
31 CABLE FOR BATTERY
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
32 PRINTER MOUNTING BASE
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
33 PRINTER GROUND POLE
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
34 PAPER TRAY SHEET
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
35 PAPER LIFTING TAPE
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
36 PRINTER SPRING
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
37 FOOTPAD1
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
38 FOOTPAD2
Included with:
“FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
“FRU Kits, PN 2039945-001” on page 5-20
800 Upper Level Assembly (Continued)
Item Part Number Item Description
