GE MAC 800 Service Manual

5-12 MAC™ 800 2031504-159D
Parts Lists
39 FOOTPAD3
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
43 HINGE LEFT
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
44 HINGE RIGHT
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
45 ST2 9X9.5 SELF TAPPING SCREW NI
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
46 BOTTOM COVER
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
47 HANDLE BOTTOM
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
48 HANDLE TOP
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
49 M3X10 MACHINE SCREW PHILIPS PAN NI
Included with:
 “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
 “FRU Kits, PN 2039945-001” on page 5-20
50 AC INLET MODULE
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
52 AC INLET HOUSE MODULE
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
53 PCB MAC800 BATTERY INTERFACE BD
Included with “FRU Bottom Cover Assembly, PN 2039943-001” on page 5-15
54 2039944-001 MAC800 FRU BATTERY ASSEMBLY
55 2039947-001 MAC800 FRU INTERNAL MODEM (OPTION)
57 2027268-004 CARD SECURE DIGITAL 512MB
2027268-005 CARD SECURE DIGITAL 2GB
58 2040058-001 MAC800 FRU CD & MANUAL
59 2040760-001 FRU MAC800 PROGRAMMED SD CARD
60 401981-001 BATTERY LITH PC COIN TYPE 3.0V
Included with “MAC800 FRU Battery Coin 3V, PN 2044674-001” on page 5-19
