GE Mini Field Agent - Overview

Configuring the Mini Field Agent
Perform the following procedure to install and configure the Mini
Field Agent device for use in the Carestation Insights solution.
Preparing Mini Field Agent for Boot Up
To prepare the Mini Field Agent for bootup, perform the following
steps:
The Mini Field Agent Network port has been pre-configured with the
IP address 192.168.101.2 and subnet mask of 255.255.255.0.
AC.26p013
Computer
eth0
eth1
Capsule
Server
Facility
Network
Switch
Power
Supply
SBX
Figure 3 • Mini Field Agent integration diagram
1. Connect the Mini Field Agent WAN Port 0 to the computer
ethernet port, using an ethernet cable.
2. Connect the Mini Field Agent LAN Port 1 to the Facility network
switch, using an ethernet cable.
3. Connect the Mini Field Agent to the power supply.
Note
