CHAPTER 6: SETPOINTS S1 RELAY SETUP
350 FEEDER PROTECTION SYSTEM – INSTRUCTION MANUAL 6–27
0xD344 Ntrl Dir Rev DPO
0xD382 Gnd Dir Rev OP
0xD384 Gnd Dir Rev DPO
0xDC01 LE 9 PKP
0xDC02 LE 9 OP
0xDC04 LE 9 DPO
0xDC41 LE 10 PKP
0xDC42 LE 10 OP
0xDC44 LE 10 DPO
0xDC81 LE 11 PKP
0xDC82 LE 11 OP
0xDC84 LE 11 DPO
0xDCC1 LE 12 PKP
0xDCC2 LE 12 OP
0xDCC4 LE 12 DPO
0xDD01 LE 13 PKP
0xDD02 LE 13 OP
0xDD04 LE 13 DPO
0xDD41 LE 14 PKP
0xDD42 LE 14 OP
0xDD44 LE 14 DPO
0xDD81 LE 15 PKP
0xDD82 LE 15 OP
0xDD84 LE 15 DPO
0xDDC1 LE 16 PKP
0xDDC2 LE 16 OP
0xDDC4 LE 16 DPO
0xE002 Any Block
0xE042 Therm O/L Blck
0xE182 Output Relay 1 BLK
0xE1C2 Output Relay 2 BLK
0xE882 Group Change Blk
0xEB02 AR Block
0xEE82 CLP Ph IOC1 BLK
0xEEC2 CLP Ph IOC2 BLK
0xEF02 CLPNtrlIOC1 BLK
0xEF42 CLPNtrlIOC2 BLK
0xEF82 CLP GndIOC1 BLK
0xEFC2 CLP GndIOC2 BLK
0xF002 Ph IOC1 Block
0xF042 Ntrl IOC1 Block
0xF082 Gnd IOC1 Block
0xF0C2 Ph TOC1 Block
0xF102 Ntrl TOC1 Block
0xF142 Gnd TOC1 Block
0xF182 Ph IOC2 Block
0xF1C2 Ntrl IOC2 Block
Code Type Definition
