34
Sub Meters GE Multilin
The panel or housing in which the EPM 2000 is mounted, should protect it from dust,
moisture, oil, corrosive vapors, etc.
The panel doors must be easily opened to provide easy access to the EPM 2000 wiring for
trouble-shooting. Allow clearance if the unit is going to swing out, as well as adequate slack
in the wiring. Allow space for terminal blocks, CT shorting blocks, fuses, auxiliary
contractors and other necessary components.
4.1.2.3.
Viewing
For ease of operation, in the location should be preferably at, or slightly above, eye-level. For
viewing comfort, minimize glare and reflections from strong light sources.
4.1.3. Mounting
Before Mounting and Wiring, the Setup procedure should have been completed.
The EPM 2000 is panel mountable.
Panel cutout :90
+1.0
-0 mm (w) x 90
+1.0
-0 mm(h) DIN 43700
Panel Thickness : 0.5 mm to 4.0 mm.
Instrumental Bezel dimension : 96 mm x 96mm
Depth behind Bezel :80 mm. Leave clearance for wires.
82 mm with Terminal Cover
Mounting Clamp Screws : Slotted, 2 nos.
Terminal Screws :Combination Phillips & Slotted head
The cut-out should be punched with the proper tool and should be free from burrs.
Before Wiring, insert the EPM 2000 into the cut-out from the front. Then, fasten the two side
clamps from the rear. While supporting the EPM 2000 from the front, tighten both side clamp
screws in a criss-cross pattern till all slack is taken up, then apply one full turn. Do not over-
tighten.
