GE Multilin Sub Meters
47
6.5. Register Map
6.5.1. RMS Total/Average Block
Start Address: 3000
Block Size: 20 Registers
Modbus Read Function Code: 03
Always transfer the Whole Block.
Add
ress
Parameters Description Data Type
3000 VA Total RMS Apparent Power 32-bit Float
3002 W Total RMS Active Energy 32-bit Float
3004 VAR Total RMS Reactive Energy 32-bit Float
3006 PF Total RMS PF 32-bit Float
3008 VLL Total RMS Line to Line Voltage 32-bit Float
3010 VLN Total RMS Line to Neutral Voltage 32-bit Float
3012 A Total RMS Current 32-bit Float
3014 F Total RMS Frequency 32-bit Float
3016 RESERVED1 Reserved for future use 32-bit Unsigned Long
3018 INTR Number of Power Interruptions 32-bit Unsigned Long
6.5.2. RMS Phase A Block
Start Address: 3030
Block Size: 20 Registers
Modbus Read Function Code: 03
Always transfer the Whole Block.
Addr
ess
Parameters Description Data Type
3030 VA
A
RMS Phase A Apparent Power 32-bit Float
3032 W
A
RMS Phase A Active Energy 32-bit Float
3034 VAR
A
RMS Phase A Reactive Energy 32-bit Float
3036 PF
A
RMS Phase A PF 32-bit Float
3038 V
AB
RMS Phase A Line to Line Voltage 32-bit Float
3040 V
A
RMS Phase A Line to Neutral
Voltage
32-bit Float
3042 A
A
RMS Phase A Current 32-bit Float
3044 F
A
RMS Phase A Frequency 32-bit Float
3046 RESERVED2 Reserved for future use 32-bit Unsigned Long
3048 INTR
A
Number of Power Interruptions 32-bit Unsigned Long
