GE Multilin EPM 2000 Series User Manual

48
Sub Meters GE Multilin
6.5.3. RMS Phase B Block
• Start Address: 3060
•
Block Size: 20 Registers
•
Modbus Read Function Code: 03
• Always transfer the Whole Block.
Addr
ess
Parameters Description Data Type
3060 VA
B
RMS Phase B Apparent Power 32-bit Float
3062 W
B
RMS Phase B Active Energy 32-bit Float
3064 VAR
B
RMS Phase B Reactive Energy 32-bit Float
3066 PF
B
RMS Phase B PF 32-bit Float
3068 V
BC
RMS Phase B Line to Line Voltage 32-bit Float
3070 V
B
RMS Phase B Line to Neutral
Voltage
32-bit Float
3072 A
B
RMS Phase B Current 32-bit Float
3074 F
B
RMS Phase B Frequency 32-bit Float
3076 RESERVED3 Reserved for future use 32-bit Unsigned Long
3078 INTR
B
Number of Power Interruptions 32-bit Unsigned Long
6.5.4.
6.5.5. RMS Phase C Block
• Start Address: 3090
•
Block Size: 20 Registers
•
Modbus Read Function Code: 03
• Always transfer the Whole Block.
Add
ress
Parameters Description Data Type
3090 VA
C
RMS Phase C Apparent Power 32-bit Float
3092 W
C
RMS Phase C Active Energy 32-bit Float
3094 VAR
C
RMS Phase C Reactive Energy 32-bit Float
3096 PF
C
RMS Phase C PF 32-bit Float
3098 V
CA
RMS Phase C Line to Line Voltage 32-bit Float
3100 V
C
RMS Phase C Line to Neutral
Voltage
32-bit Float
3102 A
C
RMS Phase C Current 32-bit Float
3104 F
C
RMS Phase C Frequency 32-bit Float
3106 RESERVED4 Reserved for future use 32-bit Unsigned Long
3108 INTR
C
Number of Power Outages 32-bit Unsigned Long
