GEK-113285A G650 Generator Protection & Control System F-21
APPENDIX F F.2 FACTORY DEFAULT CONFIGURATION
F
F.2FACTORY DEFAULT CONFIGURATION
NOTE:
SOURCE COLUMN:
This columns allow selecting the simple or complex (OR signal or Virtual output) operand that actives the selected
elements on relay configuration
If more than one operands are selected, the relay performs an OR gate with them to activate the selected element.
SIGNAL LOGIC COLUMN:
Refers to each individual signal selected on its left. NOT legend means that the refered signal is inverted
SOURCE LOGIC COLUMN:
Refers to the whole SOURCE signal selected on its left. NOT legend means that SOURCE signal is inverted
If more than one operand were selected, the OR gate output is inverted
SETPOINT>RELAY CONFIGURATION>OUTPUTS
OUTPUT ID OUTPUT NAME SOURCE SIGNAL LOGIC SOURCE LOGIC
CONT OP OPER_F_01 CONT_OP_F_01_FR
EQ PKP
VO_056_ALL_FREQUENCY_PKP
CONT OP OPER_F_02 CONT_OP_F_02_27-
59 PKP
VO_046_59P_PKP
VO_045_27P_PKP
CONT OP OPER_F_03 CONT_OP_F_03_50G
_PKP
VO_048_50G_PKP
CONT OP OPER_F_04 CONT_OP_F_04_51G
_PKP
VO_049_51G_PKP
CONT OP OPER_F_05 CONT_OP_F_05_50P
_PKP
VO_051_50PH_PKP
CONT OP OPER_F_06 CONT_OP_F_06_51P
_PKP
VO_053_51P_PKP
CONT OP OPER_F_07 CONT_OP_F_07_MA
NUAL_CLOSE
OPERATION BIT 1
CONT OP OPER_F_08 CONT_OP_F_08_GE
NERAL_TRIP
OPERATION BIT 2
VO_083_GENERAL_TRIP
CONT OP OPER_G_01 Not Configured
CONT OP OPER_G_02 Not Configured
CONT OP OPER_G_03 Not Configured
CONT OP OPER_G_04 Not Configured
CONT OP OPER_G_05 Not Configured
CONT OP OPER_G_06 Not Configured
CONT OP OPER_G_07 Not Configured
CONT OP OPER_G_08 Not Configured
CONT OP RESET_F_01 Not Configured
CONT OP RESET_F_02 Not Configured
CONT OP RESET_F_03 Not Configured
CONT OP RESET_F_04 Not Configured
CONT OP RESET_F_05 Not Configured
CONT OP RESET_F_06 Not Configured
CONT OP RESET_F_07 Not Configured
CONT OP RESET_F_08 Not Configured
CONT OP RESET_G_01 Not Configured
CONT OP RESET_G_02 Not Configured
CONT OP RESET_G_03 Not Configured
CONT OP RESET_G_04 Not Configured
CONT OP RESET_G_05 Not Configured
CONT OP RESET_G_06 Not Configured
