9–12 MULTILINK ML2400 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
PORT MIRRORING AND SETUP CHAPTER 9: PORT MIRRORING AND SETUP
9.4 Port Mirroring using EnerVista Secure Web Management Software
9.4.1 Commands
Monitoring a specific port can be done by port mirroring. Mirroring traffic from one port to
another port allows analysis of the traffic on that port.
To enable port mirroring as well as setting up the ports to be “sniffed”,
Z Select the Configuration > Port > Mirroring menu item.
Z Set the sniffer port and the port on which the traffic is reflected.
Z Make sure the Mirror Status is also set to enabled for mirroring:
For security reasons, GE Multilin recommends that the port mirroring be disabled using the
Edit button and setting the Mirror Status to off once port monitoring is completed.
Note that:
1. Only one port can be set to port mirror at a time.
