B-44 N60 Network Stability and Synchrophasor Measurement System GE Multilin
B.4 MEMORY MAPPING APPENDIX B
B
Generic Comparator Settings (Read/Write Setting (6 Modules)
8010 Comparator 1 Function 0 to 1 --- 1 F102 0 (Disabled)
8011 Comparator 1 Addition/Subtraction Mode Operand 0 to 4294967295 --- 1 F300 0
8013 Comparator 1 Scale Factor 0.01 to 100 --- 0.01 F001 100
8014 Comparator 1 Block 0 to 4294967295 --- 1 F300 0
8016 Comparator 1 Target 0 to 2 --- 1 F109 0 (Self-reset)
8017 Comparator 1 Events 0 to 1 --- 1 F102 0 (Disabled)
8018 Comparator 1 Argument A Bits (8 items) 0 to 4294967295 --- 1 F300 0
8028 Comparator 1 Input Mode 0 to 1 --- 1 F515 0 (SIGNED)
8029 Comparator 1 Direction Mode 0 to 1 --- 1 F517 0 (OVER)
802A Comparator 1 Pickup -25400 to 25400 --- 0.01 F004 1000000
802C Comparator 1 Hysteresis 0 to 5000 --- 0.01 F003 50000
802E Comparator 1 Pickup Delay 0 to 65.353 s 0.001 F001 0
802F Comparator 1 Reset Delay 0 to 65.353 s 0.001 F001 0
8030 Comparator 1 Argument B Bits (8 items) 0 to 4294967295 --- 1 F300 0
8040 Reserved (4 items) 0 to 65535 --- 1 F001 0
8044 ...Repeated for Comparator 2
8078 ...Repeated for Comparator 3
80AC ...Repeated for Comparator 4
80E0 ...Repeated for Comparator 5
8114 ...Repeated for Comparator 6
Generic Comparator Actual Values (Read Only) (6 Modules)
8150 Comparator 1 Argument A value -12700 to 12700 --- 0.01 F004 0
8152 Comparator 1 Argument B value -12700 to 12700 --- 0.01 F004 0
8154 Comparator 1 Output Value -25400 to 25400 --- 0.01 F004 0
8156 ...Repeated for comparator 2
815C ...Repeated for comparator 3
8162 ...Repeated for comparator 4
8168 ...Repeated for comparator 5
816E ...Repeated for comparator 6
Direct Analog Input Actual Values (Read Only) (32 Modules)
8180 Direct Analog Input 1 Value 0 to 2147483647 --- 0.01 F060 0
8182 Direct Analog Input 2 Value 0 to 2147483647 --- 0.01 F060 0
8184 Direct Analog Input 3 Value 0 to 2147483647 --- 0.01 F060 0
8186 Direct Analog Input 4 Value 0 to 2147483647 --- 0.01 F060 0
8188 Direct Analog Input 5 Value 0 to 2147483647 --- 0.01 F060 0
818A Direct Analog Input 6 Value 0 to 2147483647 --- 0.01 F060 0
818C Direct Analog Input 7 Value 0 to 2147483647 --- 0.01 F060 0
818E Direct Analog Input 8 Value 0 to 2147483647 --- 0.01 F060 0
8190 Direct Analog Input 9 Value 0 to 2147483647 --- 0.01 F060 0
8192 Direct Analog Input 10 Value 0 to 2147483647 --- 0.01 F060 0
8194 Direct Analog Input 11 Value 0 to 2147483647 --- 0.01 F060 0
8196 Direct Analog Input 12 Value 0 to 2147483647 --- 0.01 F060 0
8198 Direct Analog Input 13 Value 0 to 2147483647 --- 0.01 F060 0
819A Direct Analog Input 14 Value 0 to 2147483647 --- 0.01 F060 0
819C Direct Analog Input 15 Value 0 to 2147483647 --- 0.01 F060 0
819E Direct Analog Input 16 Value 0 to 2147483647 --- 0.01 F060 0
81A0 Direct Analog Input 17 Value 0 to 2147483647 --- 0.01 F060 0
81A2 Direct Analog Input 18 Value 0 to 2147483647 --- 0.01 F060 0
81A4 Direct Analog Input 19 Value 0 to 2147483647 --- 0.01 F060 0
81A6 Direct Analog Input 20 Value 0 to 2147483647 --- 0.01 F060 0
81A8 Direct Analog Input 21 Value 0 to 2147483647 --- 0.01 F060 0
81AA Direct Analog Input 22 Value 0 to 2147483647 --- 0.01 F060 0
81AC Direct Analog Input 23 Value 0 to 2147483647 --- 0.01 F060 0
Table B–10: MODBUS MEMORY MAP (Sheet 36 of 70)
ADDR REGISTER NAME RANGE UNITS STEP FORMAT DEFAULT
