Page 19
NOTE: To null a zone, program the zone in APartition Select@ as zero (0) in all partitions and do
not use end-of-line resistors.
LOCATION 25
ZONE TYPE FOR ZONES 1-8
8 segments, numerical data
Location 25 contains the zone type (configuration) for zones 1-8. Segment 1 is for zone 1, and Segment 8 is for zone 8.
Default zone types are found in the Table 1.1 on page 18. To customize a zone type, see loc. 110 - 149, page 28.
LOCATION 26
PARTITION SELECT, ZONES 1-8
8 segments, feature selection
Location 26 is used to select the partition(s) that zones 1 - 8 reside in. A zone may reside in any combination of the 2
partitions. If a burglary zone resides in more than 1 partition, it will only be active when all partitions it
resides in are armed. A zone that resides in more than 1 partition will be reported to its lowest partition
number. Location 26 has 8 segments. Segment 1 corresponds to zone 1, and Segment 8 corresponds to zone 8.
Segments 1- 8
â Partition #1
ã Partition #2
LOCATION 27
ZONE TYPE FOR ZONES 9-16
8 segments, numerical data
Location 27 contains the zone type (configuration) for zones 9 -16. Segment 1 is for zone 9, and Segment 8 is for zone
16. Default zone types are found in Table 1.1 on page 18. To customize a zone type, see page 28.
LOCATION 28
PARTITION SELECT, ZONES 9-16
8 segments, feature selection
Location 28 is used to select the partition(s) that zones 9-16 reside in. A zone may reside in any combination of the 2
partitions. If a burglary zone resides in more than 1 partition, it will only be active when all partitions it
resides in are armed. A zone that resides in more than 1 partition will be reported to its lowest partition.
Location 28 has 8 segments. Segment 1 corresponds to zone 9 and Segment 8 corresponds to zone 16.
Segments 1- 8
â Partition #1
ã Partition #2
LOCATION 37
SIREN AND SYSTEM SUPERVISION
5 segments, feature selection
Location 37 is used to enable various system feature and reporting options. (Refer to the feature definitions.)
Segment 1
â On if siren sounds for "Telephone Line Cut" when armed.
ã On if siren sounds for "Telephone Line Cut" when disarmed.
ä On if siren blast at arming.
å On if siren blast at exit expiration.
æ On if siren blast at closing kissoff.
ç On if siren sounds during a "Cross Zone" verification time.
è On if siren sounds for a Zone or Box Tamper.
é On if siren blasts 1 time for keyswitch or wireless arming; 2 times for disarming. (NOTE:
This feature must be disabled for SIA CP-01 installations.)
Segment 2
â On if siren driver should be a voltage output. Off if on board siren driver enabled.
ã On if siren sounds for expander trouble (required for UL installations).
ä On for Immediate Restore by Zone.
å On if Dynamic Battery Test performed at arming. Off if performed at disarming. (Loc. 40)
æ On if Battery Missing Test is performed every 12 seconds.
ç On if Manual Bell Test performed during [r]-[4] test function.
è On if Manual Communicator Test performed during [r]- [4] test function.
é On if Box Tamper terminals on the control panel are enabled.
Segment 3
â On if Box Tamper reporting enabled.
ã On if AC Fail reporting enabled.
ä On if Low Battery reporting enabled.
å On if Aux. Power Over current reporting enabled.
æ On if Siren Supervision reporting enabled.
ç On if Telephone Line Cut reporting enabled.
è Reserved.
é On if Expander Trouble reporting enabled.
