Segment 4
â On if Fail To Communicate report enabled.
ã On if Log Full report enabled.
ä On if Autotest report enabled.
å On if Start/End programming report enabled.
æ On if End Download report enabled.
ç On if Sensor Low Battery report enabled.
è On if Sensor Missing report enabled.
é Reserved.
Segment 5
â On enable Lost Clock service light.
ã On enables Zone Doubling for zones 7 -12 (requires NX-200 Zone Doubling Kit).
ä On disables on-board zones.
å On will allow two trips on same cross-zone to activate an alarm.
æ On will not allow zones that are force armed to report bypass.
ç Reserved
è Use internal crystal for clock.
é Disable Temporal Siren on Fire. (Note: Must not be disabled for UL listed systems.
)
Refer to the feature definitions beginning on page 3.
LOCATION 38
SWINGER SHUTDOWN COUNT
Location 38 contains the number of trips on a zone before that zone is bypassed automatically. Refer to the feature
definitions beginning on page 3. Factory default is 1.
LOCATION 39
KEYPAD SOUNDER CONTROL
1 segment, feature selection
â On if keypad sounds for ATelephone Line Cut@ when the system is armed.
ã On if keypad sounds for ATelephone Line Cut@ when disarmed.
ä On if keypad sounds upon AC Power Failure.
å On if keypad sounds when a Low Battery is detected.
æ On if keypad sounds during Cross Zone trip time.
ç On if keypad sounds for zone and box tampers.
è Reserved.
é On if keypad sounds for expander trouble (required for UL installations).
LOCATION 40
SYSTEM TIMERS
10 segments, numerical data
Location 40 contains the duration of various system timing functions. Example: If you desire the duration of the
Dynamic Battery Test to be 30 minutes, you should program [3]-[0]-[r] in segment 1 of this location. The [3]-[0] is the
number of minutes, and the [r] stores the data and moves to the next segment of this location.
SEGMENT DESCRIPTION SELECTIONS DEFAULT NOTES
1 Dynamic Battery Test
duration
0 - 255 minutes 0 "0" = no test
The "Dynamic Battery Test" feature cannot
exceed 4 hours for UL residential fire
installations.
2 AC Fail report delay 0 - 255 minutes 5 0 = no delay
3 Power Up delay 0 - 60 seconds 60 0 = no delay
4 Siren time 1 - 254 minutes 8
5 Telephone Line Cut delay 0 - 255 seconds 0 0 = no TLM
6 Cross Zone time 0 - 255 minutes 5 0 = no Cross Zoning
7 Chime time in 50 mS
(1/20th second) increments
0 - 255 mS 3 255 mS = 12 seconds
0 follows zone, 255 is latched
8 Dial delay 15 - 255 seconds 30 The "Dial Delay" feature shall be set to –0- for
UL Listed systems. Must be disabled by zone
type in Loc 110-169.
The combined Dial Delay and Entry Delay (loc
24) must not exceed 1 minute fro SIA CP-01
requirements.
9 Fire Alarm Verification time 120 - 255
seconds
0 0= no Fire Alarm Verification
This feature is not approved for residential
use in California.
10 Listen-In time 0 - 255 seconds 0 0 = no Listen-In time
The "Listen-In" feature cannot be enabled for
UL Listed systems.
