GE NetworX NX-6 User Manual

Page
30
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
PHONE #3, SELECT EVENTS TO REPORT TO PHONE #3 16 15
Segment #1
1 - Alarms and Restores “
2 - Open / Close “
3 - Bypass “
4 - Zone Trouble “
5 - Power Trouble (AC Fail or Low Battery) “
6 - Siren & Telephone Fault “
7 - Test Reports “
8 - Program, Download, & Log Full “
Segment # 2
1 - Tampers “
2 - Short Circuit “
3 - Sensor Lost “
4 - Sensor Low Battery “
5 - Expander Trouble “
6 - Failure to Communicate “
7 - Reserved
8 - Reserved
PHONE #3 SELECT WHICH PARTITIONS REPORT TO PHONE #3 17 16
1 - Partition #1 “
2 - Partition #2 “
FORMAT OVERRIDE
Segment #1 Segment #2
18 16
1 -
2 -
3 -
4 -
5 -
6 -
7 -
8 -
TURN AON@ FOR
:
1800hz transmit “
2300hz handshake “
Cksum parity “
2 digit event code “
Reserved
Reserved
20 p.p.s. “
10 p.p.s. “
TURN AOFF@ FOR
:
1900hz “
1400hz “
double round parity “
1 digit code “
Reserved
Reserved
10 or 40 p.p.s. “
20 or 40 p.p.s. “
TURN AON@ FOR
:
1 - Pager format (no handshake required) “
2 - 1400/2300 handshake “
3 - Reserved
4 - Reserved
5 - Contact ID “
6 - SIA “
7 - Contact ID or 4+3 “
8 - DTMF “
19 16 DOWNLOAD ACCESS CODE 8-4-8-0-0-0-0-0 __ __ __ __ __ __ __ __
20 16 RINGS TO ANSWER DOWNLOAD 8 __
DOWNLOAD CONTROL 21 16
1 - Enables two call answering machine defeat “
2 - Enables tone sniff answering machine defeat “
3 - Requires callback before downloading “
4 - Shutdown control panel “
5 - Lock out local programming “
6 - Lock out communicator programming “
7 - Lock out download section “
8 - Enables callback at autotest interval “
22 16 CALLBACK PHONE NUMBER 14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-
14-14-14-14
__ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __
__ __ __ __
FEATURE SELECTION, PARTITION #1 23 17
Segment #1
1 - Quick Arm “
2 - Re-Exit “
3 - Auto Bypass “
4 - Silent Panic “
5 - Audible Panic “
6 - Auxiliary 1 “
7 - Auxiliary 2 “
8 - Multi Keypress Tamper “
Segment #2
1 - LED extinguish enable “
2 - Require user code for bypassing zones “
3 - Bypass sounder alert “
4 - AC power/low battery sounder alert “
5 - Enables bypass toggle “
6 - Enables silent auto arm “
7 - Enables automatic instant “
8 - Reserved
Segment #3
1 - Open/Close “
2 - Bypass “
3 - Restore “
4 - Trouble “
5 - Tamper “
6 - Cancel “
7 - Recent Closing “
8 - Exit Error “
ENTRY/EXIT TIMERS, PARTITION 1 24 17
Segment #1 (Entry Time #1)
Segment #2 (Exit Time #1)
Segment #3 (Entry Time #2)
Segment #4 (Exit Time #2)
30
60
30
60
__
__
__
__
25 19 ZONES 1-8, ZONE TYPES 3-5-6-6-6-6-6-6 __ __ __ __ __ __ __ __
ZONES 1-8, PARTITION SELECTION (Segment 1=Zone 1 thru Segment 8=Zone 8) 26 19
Segment #1
1 - Partition #1 “
2 - Partition #2 “
Segment # 2
1 - Partition #1 ‘
2 - Partition #2 ‘
Segment #3
1 - Partition #1 “
2 - Partition #2 “
Segment #4
1 - Partition #1 “
2 - Partition #2 “
Segment #5
1 - Partition #1 “
2 - Partition #2 “
Segment #6
1 - Partition #1 “
2 - Partition #2 “
Segment #7
1 - Partition #1 “
2 - Partition #2 “
Segment #8
1 - Partition #1 “
2 - Partition #2 “

GE NetworX NX-6 Specifications

Operating Power

operating power	16.5 VAC 25, 40, or 50 VA Transformer
auxiliary power with 25 VA transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA transformer	12 VDC Regulated 1 AMP

Loop Specifications

loop resistance for standard loop	300 Ohms Maximum
loop resistance for 2-wire smokes	30 Ohms Maximum
loop response	500mS

Operating Environment

operating temperature	32 to 120 degrees F

LED Keypad Specifications

led keypad current draw	130 mA max.
led keypad dimensions width	6.4"
led keypad dimensions height	4.0"
led keypad dimensions depth	1.1"

NX-148E LCD Keypad Specifications

nx-148e lcd keypad current draw	110 mA max.
nx-148e lcd keypad dimensions width	6.4"
nx-148e lcd keypad dimensions height	5.3"
nx-148e lcd keypad dimensions depth	1.0"

Enclosure and Shipping

metal enclosure dimension width	11.25"
metal enclosure dimension height	11.25"
metal enclosure dimension depth	3.50"
shipping weight	9 lbs.
