NX-6V2 Control
Segment 3:
1- On enables Fast Loop Response. (50mS)- Off= 500mS
2- On enables Double End Of Line Tamper zone. (Mainly used for tamper on wireless zones)
3- On enables Trouble Reporting zone. (Day zone and Fire zones)
4- On if Zone Type is a Cross Zone.
5- On enables Dialer Delay zone. (See location 40, page 19)
6- On if Zone Type will swinger shutdown. (See location 38, page 19)
7- On enables Restore reporting.
8- On enables Listen-In. (See location 40, page 19)
Segment 4:
1 = On enables Zone Activity Monitor. (See location 40, page 19)
2 = On enables End of Line Resistor Defeat on Non-Fire/Non-Keyswitch zones.
3 = On enables zone to act as request to exit input / disables for alarm activation.
4 = On enables zone to act as access entry point (Refer to NX-1700E card reader instruction manual. Do not
enable this segment
unless configured with Access Control.)
5-8 = Reserved.
Segment 5: Reserved.
112 ZONE TYPE 2 ALARM EVENT CODE 1 ............ numerical
Location 112 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
113 ZONE TYPE 2 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
114 ZONE TYPE 3 ALARM EVENT CODE 1 ............ numerical
Location 114 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
115 ZONE TYPE 3 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
116 ZONE TYPE 4 ALARM EVENT CODE 1 ............ numerical
Location 116 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
117 ZONE TYPE 4 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
118 ZONE TYPE 5 ALARM EVENT CODE 1 ............ numerical
Location 118 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
119 ZONE TYPE 5 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
120 ZONE TYPE 6 ALARM EVENT CODE 1 ............ numerical
Location 120 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
121 ZONE TYPE 6 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
122 ZONE TYPE 7 ALARM EVENT CODE 1 ............ numerical
Location 122 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
123 ZONE TYPE 7 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25
124 ZONE TYPE 8 ALARM EVENT CODE 1 ............ numerical
Location 124 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 43. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 25 for details.
125 ZONE TYPE 8 CHARACTERISTIC SELECT 5 ............ feature select
Use "Zone Type Characteristic Selections" described in Location 111, page 25

GE NetworX NX-6V2 Specifications

Power

operating power	16.5 VAC 40, or 50 VA Transformer
auxiliary power with 25 VA Transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA Transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E Power Supply	12 VDC Regulated 2 AMPS + Control Panel Power

Loop Specifications

loop resistance standard loop	300 Ohms Maximum
loop resistance 2-wire smokes	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F

Keypad Specifications

LED keypad current draw	130 mA max.
LED keypad zones normal without sounder	55 mA
LED keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
NX148E LCD keypad current draw	110 mA max.
NX148E LCD keypad without sounder	75 mA
NX148E LCD keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep

Dimensions and Weight

metal enclosure dimension	11.25" Wide, 11.25" High, 3.50" Deep
shipping weight	9 lbs.
