GE NetworX NX-6V2 User Manual

32
NX-6V2 Control
LOC PG DESCRIPTION DEFAULT PROGRAM DATA
17 14 PHONE 3, SELECTING WHICH PARTITIONS REPORT TO PHONE 3
Segment 1 (Circle Numbers To Program)
1 = Partition 1
2 = Partition 2
18 15 FORMAT OVERRIDE
Segment 1 (Circle Numbers To Program) Segment 2 (Circle Numbers To Program)
1 = ON - 1800hz transmit; OFF - 1900hz
2 = ON - 2300hz handshake; OFF - 1400hz.
3 = ON - cksum parity; OFF - double round parity
4 = ON - 2 digit event code; OFF - 1 digit code
5 = Reserved.
6 = Reserved.
7 = ON - 20 p.p.s.; OFF - 10 or 40 p.p.s.
8 = ON - 10 p.p.s.; OFF - 20 or 40 p.p.s.
1 = ON - pager format (no handshake required)
2 = ON - 1400/2300 handshake
3 = Reserved
4 = Reserved
5 = ON - Contact ID
6 = ON - SIA
7 = ON - Contact ID or 4+3
8 = ON - DTMF
Segments 3 & 4 RESERVED
L
19 15 DOWNLOAD ACCESS CODE 8-4-8-0-0-0-0-0 _ _ _ _ _ _ _ _
L
20 15 RINGS TO ANSWER DOWNLOAD 8 _
L
21 15 DOWNLOAD CONTROL
Segment 1 (Circle Numbers To Program)
1 = Enables two call answering machine defeat
2 = Enables tone sniff answering machine defeat
3 = Requires callback before downloading
4 = Shutdown control panel
5 = Lock out local programming
6 = Lock out communicator programming
7 = Lock out download section
8 = Enables callback at autotest interval
L
22 15 CALLBACK PHONE NUMBER 14-14-14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-14-14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
L
23 15 PARTITION 1, FEATURE SELECTION
Segment 1 (Circle Numbers To Program)
1 = Quick Arm
2 = Re-Exit
3 = Auto Bypass
4 = Silent Panic
5 = Audible Panic
6 = Auxiliary 1
7 = Auxiliary 2
8 = Multi Keypress Tamper
Segment 2 (Circle Numbers To Program)
1 = LED extinguish enable
2 = Require user code for bypassing zones
3 = Bypass sounder alert
4 = AC power/low battery sounder alert
5 = Enables bypass toggle
6 = Enables silent auto arm
7 = Enables automatic instant
8 = Enables Instant mode toggle
Segment 3 (Circle Numbers To Program)
1 = Open/Close
2 = Bypass
3 = Restore
4 = Trouble
5 = Tamper
6 = Cancel
7 = Recent Closing
8 = Exit Error
Segment 4 (Circle Numbers To Program)
1 = Late to Close / Early to Open
2 = Auto Arm in Stay Mode
3 = Disables door delays in Night mode
4-8 = Reserved
Segment 5 RESERVED
L
24 16 ENTRY / EXIT TIMERS
Segment 1 (Entry Time 1) 30
Segment 2 (Exit Time 1) 60
Segment 3 (Entry Time 2) 30
Segment 4 (Exit Time 2) 60
Segments 5 & 6 Reserved
L
25 18 ZONES 1-8, ZONE TYPES 3-5-6-6-6-6-6-6 _ _ _ _ _ _ _ _
26 18 ZONES 1-8, PARTITION SELECTION (Segment 1=Zone 1 thru Segment 8=Zone 8)
Segments(Zone) 1 2 3 4 5 6 7 8
Partition 1
Partition 2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
L
27 18 ZONES 9-16, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _
28 18 ZONES 9-16, PARTITION SELECTION (Segment 1=Zone 9 thru Segment 8=Zone 16)
Segments(Zone) 1(9) 2(10) 3(11) 4(12) 5(13) 6(14) 7(15) 8(16)
Partition 1
Partition 2
1
2
1
2
1
2
1
2
1
2
1
2
1
2
1
2

GE NetworX NX-6V2 Specifications

Power

operating power	16.5 VAC 40, or 50 VA Transformer
auxiliary power with 25 VA Transformer	12 VDC Regulated 500 mA
auxiliary power with 40 or 50 VA Transformer	12 VDC Regulated 1 AMP
auxiliary power with NX-320E Power Supply	12 VDC Regulated 2 AMPS + Control Panel Power

Loop Specifications

loop resistance standard loop	300 Ohms Maximum
loop resistance 2-wire smokes	30 Ohms Maximum
loop response	Selectable 50mS or 500mS

Operating Environment

operating temperature	32 to 120 degrees F

Keypad Specifications

LED keypad current draw	130 mA max.
LED keypad zones normal without sounder	55 mA
LED keypad dimensions	6.4" Wide, 4.0" High, 1.1" Deep
NX148E LCD keypad current draw	110 mA max.
NX148E LCD keypad without sounder	75 mA
NX148E LCD keypad dimensions	6.4" Wide, 5.3" High, 1.0" Deep

Dimensions and Weight

metal enclosure dimension	11.25" Wide, 11.25" High, 3.50" Deep
shipping weight	9 lbs.
