NX-8E CONTROL
15
L LOCATION 8 - COMMUNICATOR FORMAT FOR PHONE # 2 (1 segment, numerical data)
Location 8 contains the communicator format used to transmit to the receiver connected to Phone #2. Consult the
instruction manual for your central station receiver to determine which format is compatible, and select from Table X-1
COMMUNICATOR FORMAT SELECTIONS on page 13. If you require a format other than those listed, review the
override options described in Location 18 to build the appropriate format. A "15" must be programmed in location 8 in
addition to the entries in location 18 in order to create a special format. If this location contains a "0", format 1 will be
used when Phone #2 is dialed.
LOCATION 9 - DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE #2 (2 segments, numerical data)
Segment 1, Dial attempts: Segment 1 of Location 9 is used to enter the number of dial attempts (1 to 15 attempts)
the communicator will make to Phone #2 before ending the notification process. Factory default is "8" and the
communicator will make the same number of attempts as those programmed in location 3.
Segment 2, Phone #2 Backup Control: Programming a "0" in Segment 2 of this location will cause the NX-8E to
make the designated number of attempts to Phone #1 before setting the "Fail To Communicate" condition and stop
reporting. Programming a "1" in this segment will cause the NX-8E to stop trying to communicate after the designated
number of attempts have been made to Phone #2. If a "2" is programmed in this segment, it will cause the NX-8E to
make the dial attempts in increments of two. The first two attempts will be made to Phone #2, the next two attempts to
Phone #1, then repeating until the total number of attempts designated in Segment 1 is completed.
REPORTING EVENTS TO PHONE NUMBER 2
Phone #2 can be used to back up Phone #1 or for a second receiver to multi-report or split report events. Phone #2
has two programming locations that are used to select which events are reported to this phone number. Location 10 is
used to select which events are reported to Phone #2, and location 11 is used to select which partitions are reported
to Phone #2. If dual or split reporting is not desired, location 10 and location 11 should be left at the factory default of
"0". If multi-reporting or split reporting is desired, and the split is based on the event type (such as alarm, open close
etc.), location 10 should be used to select only those events that should be reported to Phone #2, and location 11
should be left at the factory default of "0". If dual or split reporting is desired, and the split is based on partition, then
location 10 should be programmed as "0", and location 11 should be used to select those partitions that should be
reported to the Phone #2. If no events should be reported to Phone #2, both locations should be "0".
LOCATION 10 - EVENTS REPORTED TO PHONE #2 (2 segments of feature selection data)
Segment 1: 1 = Alarms and Alarm Restores.
2 = Opening and Closings.
3 = Zone Bypass and Bypass Restores.
4 = Zone Trouble and Trouble Restores.
5 = Power Fail, Low Battery, Power Restore, and Low Battery Restore.
6 = Bell Cut, Telephone Line Cut, Bell Cut Restore, Telephone Line Restore.
7 = Test Reports.
8 = Start and End programming, Download complete.
Segment 2: 1 = Zone and Box Tamper and Tamper Restore.
2 = Auxiliary Power Overcurrent and Ground Fault and Restore for both.
3 = Sensor Missing and Restore.
4 = Sensor Low Battery and Restore.
5 = Expander Trouble and Restore.
6 = Fail To Communicate.
7 = Zone Activity Monitor.
8 = Reserved.
