NX-8E CONTROL
19
Segment 4: 1 – On enables Late to Close / Early to Open.
2 – On enables Auto Arm in Stay Mode.
3 – On disables the door delays in Night mode. (Applies to NX1208E / NX1248E)
4 - 8 Reserved.
Segment 5: Reserved
L LOCATION 24 - ENTRY / EXIT TIMERS (6 segments, numerical data)
Location 24 is used to program the Entry/Exit times. There are 2 separate Entry/Exit times.
Segment 1, Entry time 1: This is the entry time that will be used when a delay 1 zone type initiates an entry
delay. Valid entries are 10-255 seconds.
Segment 2, Exit time 1: This is the exit time that will be used for all zones designated as delay 1. Valid entries
are 10-255 seconds.
Segment 3, Entry time 2: This is the entry time that will be used when a delay 2 zone type initiates an entry
delay. Valid entries are 10-255 seconds.
Segment 4, Exit time 2: This is the exit time that will be used for all zones designated as delay 2. Valid entries
are 10-255 seconds.
Segments 5 & 6 Reserved.
XI. DEFAULT ZONE TYPES (Configurations)
Zones can be programmed to be one of thirty different zone types (configurations). Zone types # 17 - 20 can be used
for wireless or hardwired zones using European double EOL configuration. The default zone types are listed below.
These zone types can be customized by programming locations 110-169.
DATA DESCRIPTION OF DEFAULT ZONE TYPES
1 DAY ZONE - Instant when system is armed trouble zone when system is disarmed.
2
24-HOUR AUDIBLE - Creates an instant yelping siren
alarm regardless of the armed state of the control
panel.
3
ENTRY/EXIT DELAY 1-
A trip will start entry delay 1. The lack of a trip during exit delay will enable the
Automatic Bypass or Instant mode if so programmed.
4
FOLLOWER WITH AUTO- BYPASS DISABLED -
This zone will be instant when the system is armed and no
entry or exit delays are being timed. It is delayed during entry and exit delay 1 times. This zone will not
automatically bypass even if enabled in Segment 1 of Location 23.
5
INTERIOR FOLLOWER WITH AUTO- BYPASS ENABLED -
This zone will be instant when the system is
armed and no entry or exit delay is being timed. It is delayed during entry and exit delay 1 times. This zone will
automatically bypass if enabled in Segment 1 of Location 23.
6 INSTANT - This zone creates an instant alarm whenever it is tripped and the Armed LED is on.
7
24-HOUR SILENT -
Creates an instant silent alarm regardless of the armed state of the control panel. It will
not display on the keypad.
8
FIRE - This zone will li
ght the Fire LED and sound the temporal siren each time the zone is shorted. It will also
rapidly flash the Fire LED indicating a trouble if the zone is open.
9
ENTRY/EXIT DELAY 2- A trip will start entry delay 2. The lack of a trip during exit delay wi
Automatic Bypass or Instant mode if so programmed.
10
24-HOUR SILENT SUPERVISED-
Creates an instant silent alarm regardless of the armed state of the control
panel. It will display on the keypad.
11
KEYSWITCH ZONE - This zone type will arm
and disarm the partition or partitions of the control panel that it
resides in each time the zone is shorted. Keyswitch arming will report as user #99.
12
INTERIOR FOLLOWER WITH "CROSS ZONE" ENABLED -
This zone will be instant when the system is
armed an
d no entry or exit delay is being timed. It is delayed during entry and exit delay times. If a "Cross
Zone" is not being timed it will start a "Cross Zone" timer. If a "Cross Zone" is being timed it will create an
instant alarm. This zone will automatically bypass when enabled in Segment 1 of Location 23.
13
INSTANT ENTRY GUARD -
This zone creates an instant alarm whenever it is tripped and the Stay LED is off.
It will start an entry delay time 2 if it is tripped and the system is armed and the Stay LED is on.
14
ENTRY/EXIT DELAY 1 WITH GROUP BYPASS ENABLED -
A trip will start entry delay 1. This zone will
bypass when the "Group Bypass" command is entered at the keypad. The lack of a trip during exit delay will
enable the Automatic Bypass or Instant mode if so programmed.
