GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
45
XII. PROGRAMMING WORKSHEETS
(Factory defaults for segments are in bold italics text and "Quick Start" locations are identified with the L symbol.)
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
L
0 13 PHONE #1 14-14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-14-
14-14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
L
1 13 PHONE #1, ACCOUNT CODE 10 - 10 - 10 - 10 - 10 - 10 _ _ _ _ _ _
L
2 13 PHONE #1, REPORTING FORMAT 0 _
L
3 13 PHONE #1, DIAL ATTEMPTS
BACKUP CONTROL
8
0
_
_
PHONE #1, SELECTING EVENTS TO REPORT TO PHONE #1
Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program)
4 14
1 = Alarms and Restores
2 = Open/Close
3 = Bypass
4 = Zone Trouble
5 = Power Trouble (AC Failure or Low Battery)
6 = Siren & Telephone Fault
7 = Test Reports
8 = Program, Download, & Log Full
1 = Tampers
2 = Short Circuit & Ground Fault
3 = Sensor Lost
4 = Sensor Low Battery
5 = Expander Trouble
6 = Failure To Communicate
7 = Zone Activity Monitor
8 = Reserved
PHONE #1, SELECTING WHICH PARTITIONS REPORT TO PHONE #1
Segment #1 (Circle Numbers To Program)
5 14
1 = Partition #1
2 = Partition #2
3 = Partition #3
4 = Partition #4
5 = Partition #5
6 = Partition #6
7 = Partition #7
8 = Partition #8
L
6 14 PHONE #2 14-14-14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-14-14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
L
7 14 PHONE #2, ACCOUNT CODE 10 - 10 - 10 - 10 - 10 - 10 _ _ _ _ _ _
L
8 15 PHONE #2, REPORTING FORMAT 0 _
9 15 PHONE #2, DIAL ATTEMPTS
BACKUP CONTROL
8
0
_
_
PHONE #2, SELECTING EVENTS TO REPORT TO PHONE #2
Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program)
10 15
1 = Alarms and Restores
2 = Open/Close
3 = Bypass
4 = Zone Trouble
5 = Power Trouble (AC Failure or Low Battery)
6 = Siren & Telephone Fault
7 = Test Reports
8 = Program, Download, & Log Full
1 = Tampers
2 = Short Circuit & Ground Fault
3 = Sensor Lost
4 = Sensor Low Battery
5 = Expander Trouble
6 = Failure To Communicate
7 = Zone Activity Monitor
8 = Reserved
PHONE #2, SELECTING WHICH PARTITIONS REPORT TO PHONE #2
Segment #1 (Circle Numbers To Program)
11
16
1 = Partition #1
2 = Partition #2
3 = Partition #3
4 = Partition #4
5 = Partition #5
6 = Partition #6
7 = Partition #7
8 = Partition #8
12 16 PHONE #3 14-14-14-14-14-14-14-14-14-14
-
14-14-14-14-14-14-14-14-14-
14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
13 16 PHONE #3, ACCOUNT CODE 10 - 10 - 10 - 10 - 10 - 10 _ _ _ _ _ _

GE NetworX Series Specifications

General

Model	NetworX Series
Zones	Varies by model (e.g., 8, 16, 32, 64)
Partitions	Varies by model (typically 1-8)
Keypads	Supports multiple keypads
Communication	Phone line, cellular, IP
Power Supply	16.5 VAC
Backup Battery	12VDC, 7AH
User Codes	Varies by model (e.g., 48, 150, 300)
Event Buffer	Varies by model (e.g., 200, 500, 1000 events)
Operating Temperature	0°C to 49°C (32°F to 120°F)
Communication Protocol	Contact ID, SIA
Weight	Varies by model
Dimensions	Varies by model (e.g., 14.5" x 12.5" x 3.5")
