GE NetworX Series Installation And Start-Up Manual

NX-8E CONTROL
46
LOC PG DESCRIPTION DEFAULT PROGRAMMING DATA
14 16 PHONE #3, REPORTING FORMAT 0 _
15 16 PHONE #3, DIAL ATTEMPTS
BACKUP CONTROL
8
0
_
_
16 17 PHONE #3, SELECTING EVENTS TO REPORT TO PHONE #3
Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program)
1 = Alarms and Restores
2 = Open/Close
3 = Bypass
4 = Zone Trouble
5 = Power Trouble (AC Failure or Low Battery)
6 = Siren & Telephone Fault
7 = Test Reports
8 = Program, Download, & Log Full
1 = Tampers
2 = Short Circuit & Ground Fault
3 = Sensor Lost
4 = Sensor Low Battery
5 = Expander Trouble
6 = Failure To Communicate
7 = Zone Activity Monitor
8 = Reserved
17 17 PHONE #3, SELECTING WHICH PARTITIONS REPORT TO PHONE #3
Segment #1 (Circle Numbers To Program)
1 = Partition #1
2 = Partition #2
3 = Partition #3
4 = Partition #4
5 = Partition #5
6 = Partition #6
7 = Partition #7
8 = Partition #8
18 17 FORMAT OVERRIDE
Segment #1 (Circle Numbers To Program) Segment #2 (Circle Numbers To Program)
1 = ON - 1800hz transmit; OFF - 1900hz
2 = ON - 2300hz handshake; OFF - 1400hz.
3 = ON - cksum parity; OFF -
double round
parity
4 = ON - 2 digit event code; OFF - 1 digit code
5 = Reserved.
6 = Reserved.
7 = ON - 20 p.p.s.; OFF - 10 or 40 p.p.s.
8 = ON - 10 p.p.s.; OFF - 20 or 40 p.p.s.
1 = ON - pager format (no handshake required)
2 = ON - 1400/2300 handshake
3 = Reserved
4 = Reserved
5 = ON - Contact ID
6 = ON - SIA
7 = ON - Contact ID or 4+3
8 = ON - DTMF
Segments #3 & #4 RESERVED
L
19
17
DOWNLOAD ACCESS CODE 8-4-8-0-0-0-0-0 _ _ _ _ _ _ _ _
L
20
17
RINGS TO ANSWER DOWNLOAD 8 _
L
21
18 DOWNLOAD CONTROL
Segment #1 (Circle Numbers To Program)
1 = Enables two call answering machine defeat
2 = Enables tone sniff answering machine defeat
3 = Requires callback before downloading
4 = Shutdown control panel
5 = Lock out local programming
6 = Lock out communicator programming
7 = Lock out download section
8 = Enables callback at autotest interval
L
22 18 CALLBACK PHONE NUMBER 14-14-14-14-14-14-14-14-14-
14-14-14-14-14-14-14-14-14-
14-14
__ __ __ __ __ __ __ __ __ __
__ __ __ __ __ __ __ __ __ __
