NX-8E CONTROL
76
• If the Late to Close/Early to Open feature is enabled, the Opening and Closing reports shall be enabled (Loc. 23, Seg.
4, Option 1 and Loc. 23, Seg. 3, Option 1).
• For Canadian installations, the class II transformer secure tab shall not be employed.
MINIMUM SYSTEM CONFIGURATIONS FOR UL INSTALLATIONS
(Residential Fire, Residential Burglary, Commercial Burglary)
• The NetworX NX-8E panel is necessary to initiate Residential and Commercial installations.
• At least one compatible keypad is needed for all applications.
• At least one bell fixture is required for all applications, except Grade C Central Station. For Grade A Local, the AD10-
12 bell and Grade A bell housing shall be used.
• Commercial UL applications require #NX-003-C metal enclosure. Supplied screws to be used.
• A minimum of two (2) keypads is required for Home Health applications and each keypad must be set to a unique
address.
• The wireless devices are only UL listed for residential applications.
• The DACT shall be enabled for all commercial burglary applications.
STANDBY TIME TOTAL AUXILIARY
CURRENT
STANDBY BATTERY
CAPACITY
ALARM CURRENT
24 hours 1.9 Amps 51 AH 600 mA
1.25 Amps 34 AH 1 Amp
600 mA 17 AH 1 Amp
48 hours 900 mA 51 AH 1 Amp
600 mA 34 AH 1 Amp
300 mA 17 AH 1 Amp
72 hours 600 mA 51 AH 1 Amp
400 mA 34 AH 1 Amp
200 mA 17 AH 1 Amp
• Calculations based on three 17-Amp batteries.
K
IMPORTANT!
1. If separate power supplies are necessary to accommodate additional devices, safety standards
require that each power supply be prominently marked with adequate instructions for removing all
power from the unit.
2. Dispose of used batteries according to the manufacturer’s instructions and/or local government
authorities.
3. Installation personnel should thoroughly read and understand the installation instructions and the
users manuals for the panel and all the accessories to be included with the system before attempting
to install a security system.
WARNING!
Replace only with Panasonic #LC12V4BP or Yuasa #NP4-12 battery. Observe polarity when installing a
new battery. Installing the battery backwards may cause damage to the panel. There is a risk of explosion
if the battery is replaced with an incorrect type.
NOTE
Electrical codes will vary depending upon the country and city where the system is installed. It is the
installer’s responsibility to ensure that the electrical installation is safe and conforms to all applicable
codes, laws, or regulations. Only qualified persons should connect this device to the mains supply.
