Object
Request
(Librar
y will parse)
Response
(Library will respond with)
Object
Number
Variation
Number
Description
Function Codes (dec) Qualifier Codes
(hex)
Function Codes
(dec)
Qualifier Codes (hex)
21 10 16-Bit Frozen Counter without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
`22 0 Counter Change Event - Any
V
ariation
1 (read) 06
07, 08
(no range, or all)
(limited qty)
22 1
(default - see
note 1)
32-Bit Counter Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
22 2 16-Bit Counter Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
22 5 32-Bit Counter Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
22 6 16-Bit Counter Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 0 Frozen Counter Event (Variation 0
is used to request default
variation)
1 (read) 06
07, 08
(no range, or all)
(limited qty)
23 1
(default - see
note 1)
32-Bit Frozen Counter Event 1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 2 16-Bit Frozen Counter Event 1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 5 32-Bit Frozen Counter Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
23 6 16-Bit Frozen Counter Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
30 0 Analog Input - Any Variation 1
22
(read)
(assign class)
00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
30 1 32-Bit Analog Input 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 2 16-Bit Analog Input 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 3
(default - see
note 1)
32-Bit Analog Input without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 4 16-Bit Analog Input without Flag 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
30 5 Short floating point 1 (read) 00, 01
06
07, 08
17, 27, 28
(start-stop)
(no range, or all)
(limited qty)
(index)
129 response 00, 01
17, 28
(start-stop)
(index - see note 2)
32 0 Analog Change Event - Any
V
ariation
1 (read) 06
07, 08
(no range, or all)
(limited qty)
32 1
(default - see
note 1)
32-Bit Analog Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 2 16-Bit Analog Change Event
without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 3 32-Bit Analog Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 4 16-Bit Analog Change Event with
Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 5 Short floating point Analog
Change Ev
ent without Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
32 7 Short floating point Analog
Change Event with Time
1 (read) 06
07, 08
(no range, or all)
(limited qty)
129 response 17, 28 (index)
Chapter 17 - Communications P54A/B/C/E
394 P54xMED-TM-EN-1
