5 CASE DIMENSIONS
Not all products are available in all case sizes.
5.1 CASE DIMENSIONS 40TE
E01411
Front view
A = Clearance holes
B = Mouting holes
Flush mouting panel
Panel cut-out details
Note: If mouting plate is required
use flush mounting cut out
dimentions
8 off holes Dia. 3.4
Sealing
strip
483 (19” rack)
All dimensons in mm
Secondary cover (when fitted)
Incl. wiring
Side view
max.
206.00
30.00
240.00
157.5
177.00
200.00
177.0
(4U)
202.00
181.30
10.35
159.00
23.30
155.40
168.00
A B
B A
B A
A B
Figure 196: 40TE case dimensions
