Appendix B - Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
The community name setting must be the same in both the SNMP Manager and the IED.
This column contains commissioning test settings
Opto I/P Status 0F 01
Opto I/P Status
[Binary Flag (32) Indexed String]
This menu cell displays the status of the available IED’s opto-isolated inputs as a binary string, a ‘1’ indicating an energized opto-isolated
input and a ‘0’ a de-energized one.
Relay O/P Status 0F 02
Relay O/P Status
[Binary Flag (32) Indexed String]
This menu cell displays the status of the digital data bus (DDB) signals that result in energization of the available output relays as a binary
string, a ‘1’ indicating an operated state and ‘0’ a non-operated state.
When the ‘Test Mode’ cell is set to ‘Enabled’ the ‘Relay O/P Status’ cell does not show the current status of the output relays and hence can
not be used to confirm operation of the output relays. Therefore it will be necessary to monitor the state of each contact in turn.
Test Port Status 0F 03
Test Port Status
[Binary Flag (8) Indexed String]
This menu cell displays the status of the eight digital data bus (DDB) signals that have been allocated in the ‘Monitor Bit’ cells.
Monitor Bit 1 0F 05 1060
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 2 0F 06 1062
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 3 0F 07 1064
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 4 0F 08 1066
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 5 0F 09 1068
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 6 0F 0A 1070
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 7 0F 0B 1072
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
Monitor Bit 8 0F 0C 1074
From 0 to 2047 in steps of 1
[Unsigned Integer (16 bits)]
The eight ‘Monitor Bit’ cells allow the user to select the status of which digital data bus signals can be observed in the ‘Test Port Status’ cell or
via the monitor/download port.
IED Test Mode 0F 0D Disabled
Test Mode
Contacts Blocked
The IED Test Mode menu cell is used to allow online testing to be performed on the IED without operation of the trip contacts. It also enables
a facility to directly test the output contacts by applying menu controlled test signals.
This setting influences the processing of control service frames with an IEC61850 Test mode flag. It does not influence the processing of
other incoming data, such as GOOSE.
To select test mode the IED Test Mode menu cell should be set to ‘Test’, which takes the IED out of service. It also causes an alarm condition
