Appendix B - Settings and Signals
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Global Nominal V 11 01 24/27V
30/34V
48/54V
110/125V
220/250V
Custom
Sets the nominal battery voltage for all opto inputs by selecting one of the five standard ratings in the Global Nominal V settings. If Custom
is selected then each opto input can individually be set to a nominal voltage value.
Opto Input 1 11 02 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 2 11 03 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 3 11 04 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 4 11 05 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 5 11 06 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 6 11 07 24/27V
30-34V
48-54V
110-125V
220-250V
Each opto input can individually be set to a nominal voltage value if custom is selected for the global setting. The number of inputs may be
up to 32, depending on the IED and I/O configuration.
Opto Input 7 11 08 24/27V
30-34V
48-54V
110-125V
