Appendix B - Settings and Signals
P54A/B/C/E
B142
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Reset
[Indexed String]
Setting to allow Control Inputs 31 set/ reset.
Control Input 32 12 21 No Operation
No Operation
Set
Reset
[Indexed String]
Setting to allow Control Inputs 32 set/ reset.
CTRL I/P CONFIG
13
00
This column contains settings for the type of control input (32 in all)
Hotkey Enabled 13 01 0xFFFFFFFF
From 0xFFFFFFFF to 32 in steps of 1
[Binary Flag (32 bits) Indexed String]
Setting to allow the control inputs to be individually assigned to the Hotkey menu by setting ‘1’ in the appropriate bit in the Hotkey Enabled
cell. The hotkey menu allows the control inputs to be set, reset or pulsed without the need to enter the CONTROL INPUTS column.
Control Input 1 13 10 Latched
Latched
Pulsed
[Indexed String]
Configures the control inputs as either ‘latched’ or ‘pulsed’. A latched control input will remain in the set state until a reset command is
given, either by the menu or the serial communications. A pulsed control input, however, will remain energized for 10 ms after the set
command is given and will then reset automatically (i.e. no reset command required).
Ctrl Command 1 13 11 Set/Reset
ON/OFF
SET/RESET
IN/OUT
ENABLED/DISABLED
[Indexed String]
Allows the SET / RESET text, displayed in the hotkey menu, to be changed to something more suitable for the application of an individual
control input, such as ON / OFF, IN / OUT etc.
Control Input 2 13 14 Latched
Latched
Pulsed
[Indexed String]
Configures the control inputs as either ‘latched’ or ‘pulsed’.
Ctrl Command 2 13 15 Set/Reset
ON/OFF
SET/RESET
IN/OUT
ENABLED/DISABLED
[Indexed String]
Allows the SET / RESET text, displayed in the hotkey menu, to be changed to something more suitable for the application of an individual
control input, such as ON / OFF, IN / OUT etc.
Control Input 3 13 18 Latched
Latched
Pulsed
[Indexed String]
Configures the control inputs as either ‘latched’ or ‘pulsed’.
Ctrl Command 3 13 19 Set/Reset
ON/OFF
SET/RESET
IN/OUT
ENABLED/DISABLED
[Indexed String]
Allows the SET / RESET text, displayed in the hotkey menu, to be changed to something more suitable for the application of an individual
control input, such as ON / OFF, IN / OUT etc.
Control Input 4 13 1C Latched
Latched
Pulsed
[Indexed String]
Configures the control inputs as either ‘latched’ or ‘pulsed’.
Ctrl Command 4 13 1D Set/Reset
ON/OFF
SET/RESET
IN/OUT
ENABLED/DISABLED
[Indexed String]
Allows the SET / RESET text, displayed in the hotkey menu, to be changed to something more suitable for the application of an individual
control input, such as ON / OFF, IN / OUT etc.
Control Input 5
13
20
Latched
Latched
