GE P54E - Page 728

Appendix B - Settings and Signals
P54A/B/C/E
B162
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
ERROR_RATE_100%
[Indexed String]
Tdiscrim
21
08
0.2
In order to avoid post trip mute of PLC during single pole opening, a discrimination timer can be set to avoid tripping for external faults
following a single phase internal fault.
PLC Opto Thres 21 09 48/54V
48/54V
12/15V
[Indexed String]
Sets the reset/operate voltage levels for the PLC fast scan Opto inputs.
SECURITY CONFIG
25
00
User Banner 25 01
ACCESS ONLY FOR
AUTHORISED USERS
From 1 to 3 in steps of 1
[ASCII Text]
NERC compliant user IED description
Attempts Limit 25 02 3
From 1 to 30 in steps of 1
[Unsigned Integer (16 bits)]
Defines the maximum number of failed password attempts.
Attempts Timer 25 03 2
0 or 1
[Unsigned Integer (16 bits)]
Defines the time duration used for detection of maximum failed password attempts
Blocking Timer 25 04 5
0 or 1
[Unsigned Integer (16 bits)]
Defines the time duration for which the user is blocked after exceeding the maximum attempts limit
Front Port 25 05 Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Physical Front Port
Rear Port 1 25 06 Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Physical Rear Port 1
Rear Port 2 25 07 Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Physical Rear Port 2
Ethernet Port 25 08 Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Physical Ethernet Port
Courier Tunnel 25 09 Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Logical Tunnelled courier Port
IEC61850 25 0A Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Logical IEC61850 Port
DNP3 OE 25 0B Enabled
Disabled
Enabled
[Indexed String]
Enable/disable of Logical DNP3 OverEthernet Port
Attempts Remain 25 11
Attempts Remain
[Integer]
Number of password attempts remaining
Blk Time Remain 25 12
Blk Time Remain
[Integer]
Blocking time remaining
Fallbck PW Level 25 20 0
Fallbck PW Level
[Unsigned Integer (16 bits)]
