GE P54E - GROUP 1: NEG SEQUENCE OC

Appendix B - Settings and Signals
P54A/B/C/E
B174
P54xMED-TM-EN-1
MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
Default Curve 2
Default Curve 3
Default Curve 4
[Indexed String]
Setting to determine the type of reset/release characteristic of the User defined curves.
I>2 Usr Rst Char 35 25 DT
DT
Default Curve 1
Default Curve 2
Default Curve 3
Default Curve 4
[Indexed String]
Setting to determine the type of reset/release characteristic of the User defined curves.
GROUP 1: NEG SEQ O/C
36
00
This column contains settings for Negative Sequence overcurrent
I2>1 Status 36 10 Disabled
Disabled
Enabled
[Indexed String]
Setting to enable or disable the first stage negative sequence element.
I2>1 Function 36 11 DT
DT
IEC S Inverse
IEC V Inverse
IEC E Inverse
UK LT Inverse
IEEE M Inverse
IEEE V Inverse
IEEE E Inverse
US Inverse
US ST Inverse
[Indexed String]
Setting for the tripping characteristic for the first stage negative sequence overcurrent element.
I2>1 Directional 36 12 Non-Directional
Non-Directional
Directional Fwd
Directional Rev
[Indexed String]
This setting determines the direction of measurement for this element.
I2>1 Current Set 36 15 0.2
From 0.08*I1 to 4*I1 in steps of 0.01*I1
[Courier Number (current)]
Pick-up setting for the first stage negative sequence overcurrent element.
I2>1 Time Delay 36 17 10
From 0 to 100 in steps of 0.01
[Courier Number (time-seconds)]
Setting for the operating time-delay for the first stage negative sequence overcurrent element.
I2>1 TMS 36 18 1
From 0.025 to 1.2 in steps of 0.005
[Courier Number (decimal)]
Setting for the time multiplier setting to adjust the operating time of the IEC IDMT characteristic.
I2>1 Time Dial 36 19 1
From 0.01 to 100 in steps of 0.01
[Courier Number (decimal)]
Setting for the time multiplier setting to adjust the operating time of the IEEE/US IDMT curves.
I2>1 Reset Char 36 1C DT
DT
Inverse
[Indexed String]
Setting to determine the type of reset/release characteristic of the IEEE/US curves.
I2>1 tRESET 36 1D 0
From 0 to 100 in steps of 0.01
[Courier Number (time-seconds)]
Setting that determines the reset/release time for definite time reset characteristic.
I2>2 Status 36 20 Disabled
Disabled
Enabled
[Indexed String]
Setting to enable or disable the second stage negative sequence element.
I2>2 Function 36 21 DT
DT
IEC S Inverse
IEC V Inverse
