MENU TEXT COL ROW DEFAULT SETTING AVAILABLE OPTIONS
DESCRIPTION
[Indexed String]
This setting enables CB1 to close by manual control when the system satisfies all the System Check Synchronism Stage 2 conditions as listed
under the setting CS2 Status in the SYSTEM CHECKS column.
CB1M SC CS2 48 B4 Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to close by manual control when the system satisfies all the System Check Synchronism Stage 2 conditions as listed
under the setting CB1 CS2 Status in the SYSTEM CHECKS column.
CBM SC DLLB 48 B5 Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to close by manual control when the dead line & live bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB1M SC DLLB 48 B5 Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to close by manual control when the dead line & live bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CBM SC LLDB 48 B6 Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to close by manual control when the live line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB1M SC LLDB 48 B6 Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB1 to close by manual control when the live line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CBM SC DLDB 48 B7 Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB to close by manual control when the dead line & dead bus1 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB2M SC LLDB 48 BC Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB2 to close by manual control when the live line & dead bus2 conditions are satisfied as set in the SYSTEM CHECKS
column.
CB2M SC DLDB 48 BD Disabled
Disabled
Enabled
[Indexed String]
This setting enables CB2 to close by manual control when the dead line & dead bus2 conditions are satisfied as set in the SYSTEM CHECKS
column.
Num CBs 49 50 CB1 Only
CB1 Only
CB2 Only
CB1&CB2
[Courier Number]
Setting defines which CB(s) are active for the specific installation: CB1 only, CB2 only or both CB1 & CB2.
Num CBs 49 50 CB1 Only
CB1 Only
CB2 Only
CB1&CB2
[Courier Number]
If the Num CBs setting (cell 4950 {above} in the AUTORECLOSE column) is set to CB1 Only, or CB2 Only, then this setting determines which
auto-reclose modes are permitted for the circuit breaker : single phase (AR 1P) only, both single phase and three phase (AR 1/3P), three phase
only (AR 3P), or the auto-reclosing mode is controlled by opto input signals (AR Opto) mapped via DDB's (1497) AR Mode 1P and (1498) AR
Mode 3P.
AR Mode 49 51 AR 3P
AR 1P
AR 1/3P
AR 3P
AR Opto
