P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B225
ORDINAL SIGNAL NAME ELEMENT NAME
DESCRIPTION
0
Relay 1
DDB_OUTPUT_RELAY_1
Assignment of signal to drive output Relay 1
1
Relay 2
DDB_OUTPUT_RELAY_2
Assignment of signal to drive output Relay 2
2
Relay 3
DDB_OUTPUT_RELAY_3
Assignment of signal to drive output Relay 3
3
Relay 4
DDB_OUTPUT_RELAY_4
Assignment of signal to drive output Relay 4
4
Relay 5
DDB_OUTPUT_RELAY_5
Assignment of signal to drive output Relay 5
5
Relay 6
DDB_OUTPUT_RELAY_6
Assignment of signal to drive output Relay 6
6
Relay 7
DDB_OUTPUT_RELAY_7
Assignment of signal to drive output Relay 7
7
Relay 8
DDB_OUTPUT_RELAY_8
Assignment of signal to drive output Relay 8
8
Relay 9
DDB_OUTPUT_RELAY_9
Assignment of signal to drive output Relay 9
9
Relay 10
DDB_OUTPUT_RELAY_10
Assignment of signal to drive output Relay 10
10
Relay 11
DDB_OUTPUT_RELAY_11
Assignment of signal to drive output Relay 11
11
Relay 12
DDB_OUTPUT_RELAY_12
Assignment of signal to drive output Relay 12
12
Relay 13
DDB_OUTPUT_RELAY_13
Assignment of signal to drive output Relay 13
13
Relay 14
DDB_OUTPUT_RELAY_14
Assignment of signal to drive output Relay 14
14
Relay 15
DDB_OUTPUT_RELAY_15
Assignment of signal to drive output Relay 15
15
Relay 16
DDB_OUTPUT_RELAY_16
Assignment of signal to drive output Relay 16
16
Relay 17
DDB_OUTPUT_RELAY_17
Assignment of signal to drive output Relay 17
17
Relay 18
DDB_OUTPUT_RELAY_18
Assignment of signal to drive output Relay 18
18
Relay 19
DDB_OUTPUT_RELAY_19
Assignment of signal to drive output Relay 19
19
Relay 20
DDB_OUTPUT_RELAY_20
Assignment of signal to drive output Relay 20
20
Relay 21
DDB_OUTPUT_RELAY_21
Assignment of signal to drive output Relay 21
21
Relay 22
DDB_OUTPUT_RELAY_22
Assignment of signal to drive output Relay 22
22
Relay 23
DDB_OUTPUT_RELAY_23
Assignment of signal to drive output Relay 23
23
Relay 24
DDB_OUTPUT_RELAY_24
Assignment of signal to drive output Relay 24
24
Relay 25
DDB_OUTPUT_RELAY_25
Assignment of signal to drive output Relay 25
25
Relay 26
DDB_OUTPUT_RELAY_26
Assignment of signal to drive output Relay 26
26
Relay 27
DDB_OUTPUT_RELAY_27
Assignment of signal to drive output Relay 27
27
Relay 28
DDB_OUTPUT_RELAY_28
Assignment of signal to drive output Relay 28
28
Relay 29
DDB_OUTPUT_RELAY_29
Assignment of signal to drive output Relay 29
