GE P54E - Page 795

P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B229
ORDINAL SIGNAL NAME ELEMENT NAME
DESCRIPTION
116
IM64 R5 Input 5
DDB_IM64_R5_5_IN
IM64 R5 input 5 - is driven by a message from the remote line end
117
IM64 R5 Input 6
DDB_IM64_R5_6_IN
IM64 R5 input 6 - is driven by a message from the remote line end
118
IM64 R5 Input 7
DDB_IM64_R5_7_IN
IM64 R5 input 7 - is driven by a message from the remote line end
119
IM64 R5 Input 8
DDB_IM64_R5_8_IN
IM64 R5 input 8 - is driven by a message from the remote line end
120
IM64 Output1
DDB_IM64_1_OUT
IM64 output 1 - mapping what will be sent to the remote line end
121
IM64 Output2
DDB_IM64_2_OUT
IM64 output 2 - mapping what will be sent to the remote line end
122
IM64 Output3
DDB_IM64_3_OUT
IM64 output 3 - mapping what will be sent to the remote line end
123
IM64 Output4
DDB_IM64_4_OUT
IM64 output 4 - mapping what will be sent to the remote line end
124
IM64 Output5
DDB_IM64_5_OUT
IM64 output 5 - mapping what will be sent to the remote line end
125
IM64 Output6
DDB_IM64_6_OUT
IM64 output 6 - mapping what will be sent to the remote line end
126
IM64 Output7
DDB_IM64_7_OUT
IM64 output 7 - mapping what will be sent to the remote line end
127
IM64 Output8
DDB_IM64_8_OUT
IM64 output 8 - mapping what will be sent to the remote line end
128
Relay Cond 1
DDB_OUTPUT_CON_1
Input to relay 1 output conditioner
129
Relay Cond 2
DDB_OUTPUT_CON_2
Input to relay 2 output conditioner
130
Relay Cond 3
DDB_OUTPUT_CON_3
Input to relay 3 output conditioner
131
Relay Cond 4
DDB_OUTPUT_CON_4
Input to relay 4 output conditioner
132
Relay Cond 5
DDB_OUTPUT_CON_5
Input to relay 5 output conditioner
133
Relay Cond 6
DDB_OUTPUT_CON_6
Input to relay 6 output conditioner
134
Relay Cond 7
DDB_OUTPUT_CON_7
Input to relay 7 output conditioner
135
Relay Cond 8
DDB_OUTPUT_CON_8
Input to relay 8 output conditioner
136
Relay Cond 9
DDB_OUTPUT_CON_9
Input to relay 9 output conditioner
137
Relay Cond 10
DDB_OUTPUT_CON_10
Input to relay 10 output conditioner
138
Relay Cond 11
DDB_OUTPUT_CON_11
Input to relay 11 output conditioner
139
Relay Cond 12
DDB_OUTPUT_CON_12
Input to relay 12 output conditioner
140
Relay Cond 13
DDB_OUTPUT_CON_13
Input to relay 13 output conditioner
141
Relay Cond 14
DDB_OUTPUT_CON_14
Input to relay 14 output conditioner
142
Relay Cond 15
DDB_OUTPUT_CON_15
Input to relay 15 output conditioner
143
Relay Cond 16
DDB_OUTPUT_CON_16
Input to relay 16 output conditioner
144
Relay Cond 17
DDB_OUTPUT_CON_17
Input to relay 17 output conditioner
