Appendix B - Settings and Signals
ORDINAL SIGNAL NAME ELEMENT NAME
DESCRIPTION
Assignment of signal to drive output function key LED 3 red. This LED is associated with function key 3
Assignment of signal to drive output function key LED 3 green. This LED is associated with function key 3. To drive function key LED, yellow
DDB 1044 and DDB 1045 must be active at the same time
Assignment of signal to drive output function key LED 4 red. This LED is associated with function key 4
Assignment of signal to drive output function key LED 4 green. This LED is associated with function key 4. To drive function key LED, yellow
DDB 1046 and DDB 1047 must be active at the same time
Assignment of signal to drive output function key LED 5 red. This LED is associated with function key 5
Assignment of signal to drive output function key LED 5 green. This LED is associated with function key 5. To drive function key LED, yellow
DDB 1048 and DDB 1049 must be active at the same time
Assignment of signal to drive output function key LED 6 red. This LED is associated with function key 6
Assignment of signal to drive output function key LED 6 green. This LED is associated with function key 6. To drive function key LED, yellow
DDB 1050 and DDB 1051 must be active at the same time
Assignment of signal to drive output function key LED 7 red. This LED is associated with function key 7
Assignment of signal to drive output function key LED 7 green. This LED is associated with function key 7. To drive function key LED, yellow
DDB 1052 and DDB 1053 must be active at the same time
Assignment of signal to drive output function key LED 8 red. This LED is associated with function key 8
Assignment of signal to drive output function key LED 8 green. This LED is associated with function key 8. To drive function key LED, yellow
DDB 1054 and DDB 1055 must be active at the same time
Assignment of signal to drive output function key LED 9 red. This LED is associated with function key 9
Assignment of signal to drive output function key LED 9 green. This LED is associated with function key 9. To drive function key LED, yellow
DDB 1056 and DDB 1057 must be active at the same time
Assignment of signal to drive output function key LED 10 red. This LED is associated with function key 10
Assignment of signal to drive output function key LED 10 green. This LED is associated with function key 10. To drive function key LED,
yellow DDB 1058 and DDB 1059 must be active at the same time
Function key 1 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 2 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 3 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 4 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 5 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 6 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 7 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 8 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
Function key 9 is activated. In ‘Normal’ mode it is high on keypress and in ‘Toggle’ mode remains high/low on single keypress
