P54A/B/C/E
Appendix B - Settings and Signals
P54xMED-TM-EN-1
B267
ORDINAL SIGNAL NAME ELEMENT NAME
DESCRIPTION
1795
No signal Rec.
DDB_NO_SIGNAL_RECEIVED
Indicate the communication channel don't receive signal
1796
CT1 R3 i1>
DDB_CTS_R3_1_I1
CTS R3 1 I1
1797
CT1 R3 i2/i1>
DDB_CTS_R3_1_I2I1_L
CTS R3 1 I2I1 L
1798
CT1 R3 i2/i1>>
DDB_CTS_R3_1_I2I1_H
CTS R3 1 I2I1 H
1799
CT1 R4 i1>
DDB_CTS_R4_1_I1
CTS R4 1 I1
1800
CT1 R4 i2/i1>
DDB_CTS_R4_1_I2I1_L
CTS R4 1 I2I1 L
1801
CT1 R4 i2/i1>>
DDB_CTS_R4_1_I2I1_H
CTS R4 1 I2I1 H
1802
CT1 R5 i1>
DDB_CTS_R5_1_I1
CTS R5 1 I1
1803
CT1 R5 i2/i1>
DDB_CTS_R5_1_I2I1_L
CTS R5 1 I2I1 L
1804
CT1 R5 i2/i1>>
DDB_CTS_R5_1_I2I1_H
CTS R5 1 I2I1 H
1805
Sig Fail R1
DDB_SIG_FAIL_RX_R1
No Msgs Received from Remote 1
1806
Sig Fail R2
DDB_SIG_FAIL_RX_R2
No Msgs Received from Remote 2
1807
Sig Fail R3
DDB_SIG_FAIL_RX_R3
No Msgs Received from Remote 3
1808
Sig Fail R4
DDB_SIG_FAIL_RX_R4
No Msgs Received from Remote 4
1809
Sig Fail R5
DDB_SIG_FAIL_RX_R5
No Msgs Received from Remote 5
1810
Reserved
DDB_CHB_DELAY_ENABLE
Channel 1 delay enable
1811
Reserved
DDB_CHA_DELAY_ENABLE
Channel 2 delay enable
2016
Timer in 17
DDB_TIMERIN_17
Input to Auxiliary Timer 17
2017
Timer in 18
DDB_TIMERIN_18
Input to Auxiliary Timer 18
2018
Timer in 19
DDB_TIMERIN_19
Input to Auxiliary Timer 19
2019
Timer in 20
DDB_TIMERIN_20
Input to Auxiliary Timer 20
2020
Timer in 21
DDB_TIMERIN_21
Input to Auxiliary Timer 21
2021
Timer in 22
DDB_TIMERIN_22
Input to Auxiliary Timer 22
2022
Timer in 23
DDB_TIMERIN_23
Input to Auxiliary Timer 23
2023
Timer in 24
DDB_TIMERIN_24
Input to Auxiliary Timer 24
2024
Timer in 25
DDB_TIMERIN_25
Input to Auxiliary Timer 25
2025
Timer in 26
DDB_TIMERIN_26
Input to Auxiliary Timer 26
2026
Timer in 27
DDB_TIMERIN_27
Input to Auxiliary Timer 27
2027
Timer in 28
DDB_TIMERIN_28
Input to Auxiliary Timer 28
