Service Tool and Configuration
2030047-001A Patient Data Module 4-9
ECG Filter Config
The ECG Filter Config module allows configuration of the power frequency and
ECG filter.
The power frequency of the Patient Data Module must match the power frequency of
the host patient monitor.
The ECG filter is always enabled. It can be disabled temporarily, but it will always
default to Enabled after a power cycle or reboot.
CAUTION
Do not disable ECG Filter during clinical use.
Licensing
The Licensing module is used for activating or removing license(s). To obtain a
license, contact GE technical support and provide the Patient Data Module serial
number and MAC address. See the “How to Reach Us...” page included with this
manual for contact information.
Enter the activation code and click Activate to complete the installation. Click
Remove to remove a license.
NOTE
After installation, perform the checkout procedures provided in the host patient
monitor service manual.
A new activation code must be requested and entered if the main cpu board is
replaced.
Software Transfer
The Software Transfer module is used for installing Patient Data Module software.
Follow the instructions displayed on the screen.
To power cycle the Patient Data Module, disconnect and reconnect the ePort host
interface connector.
CAUTION
Do not disconnect the power during software transfer. The Patient
Data Module could be damaged.
NOTE
After installation, perform the checkout procedures provided in the host patient
monitor service manual.
