4-8 Patient Data Module 2030047-001A
Service Tool and Configuration
434A
Configuration
The Configuration category consists of Asset Settings, ECG Filter Config,
Licensing and Software Transfer modules.
Asset Settings
The Asset Settings module displays the manufacturer’s serial number and the user
assigned asset number.
1. Enter the serial number and click Submit.
NOTE
The manufacturer’s serial number must follow the specific format found on
the serial number label on the Patient Data Module.
The manufacturer’s serial number must be edited if the main cpu board is
replaced.
464A
2. Enter the user assigned asset number and click Submit.
NOTE
The user assigned asset number can be up to 13 alphanumeric characters.
serial number
To Next Page
