7-8
P
atie
nt D
ata
Modu
le
2
030
047
-001
A
Field R
eplaceable Units
469A
NOTE
In the event that the pull tab assembly
comes apart when pulled
from the rail
slot, reass
emble as shown below
.
470A
471A
3.
Remove 2 s
hort screws at the rea
r of the mount rail and 2 long screws at the fro
nt
of the mount rail.
464A
4.
Unseat the mount rail by twistin
g it slightly
. Lift mount rail off the top housing.
Long screws
Short screw
s
61
63
