A-4 Patient Data Module 2030047-001A
Appendix A–Technical Specifications
Heart rate Heart rate averaging: 8 / 4 beats
Display update interval: 2 seconds
Heart rate accuracy: ± 1% or ± 1 beat/minute, whichever is
greater
Response time: < 6 seconds
Limit alarm delay: <10 seconds after limit alarm condition
exceeded
Heart rate alarm range: 0 to 300 beats/minute, high limit >
low limit
Arrhythmia analysis: 1 to 100 PVCs/minute
Method: QRS morphology classification and timing based on
single- or multiple-lead analysis
Arrhythmia calls: Full, lethal only, or no arrhythmia
PVC alarm limit range: 1 to 100 PVCs/minute
ST Segment analysis
Measurement description: ST segment deviation is measured and displayed for all
acquired leads
ST display: Lead label, ST deviation, current complex superimposed
over a reference complex, J-point indicator and 15-minute
mini-trends are shown for all acquired leads
Measurement point: Measured at user-selectable measurement points (0, 30, 40,
50, 60, and 80 ms) following the J point
Measurement range:
Display resolution:
ST measurement
averaging:
-12.0 mm to + 12.0 mm
0.1 mm
16 beats
ST alarm limits: ± 12 mm, high limit > low limit, for any event within a lead
group (inferior, lateral or anterior) that exceeds the alarm
limit for that group
Pace detection/rejection
Input voltage range:
Input pulse width:
Rise time:
Over/under shoot:
Mode:
Standard leads available:
±2 mV to ±700 mV
0.1 ms to 2 ms
10 μs to 100 μs
2 mV (maximum)
Pacemaker artifact rejection ‘On’ or ‘Off’.
I, II, RL, LL
