A-8 Patient Data Module 2030047-001A
Appendix A–Technical Specifications
Systolic pressure range
Diastolic pressure range
Mean pressure range
Cuff pressure range
Adult: 30 to 290 mmHg
Pediatric: 30 to 240 mmHg
Neonatal: 30 to 140 mmHg
Adult: 10 to 220 mmHg
Pediatric: 10 to 200 mmHg
Neonatal: 10 to 110 mmHg
Adult: 20 to 260 mmHg
Pediatric: 20 to 215 mmHg
Neonatal: 20 to 125 mmHg
Adult: 0 to 290 mmHg
Pediatric: 0 to 250 mmHg
Neonatal: 0 to 150 mmHg
Pressure accuracy
Automatic cycle times:
Auto zero:
Tubing length:
Automatic cuff deflation:
Static: ±2% or ±3 mmHg, whichever is greater
Clinical: ±5 mmHg average error, 8 mmHg standard deviation
0 to 24 hours
Zero pressure reference prior to each cuff inflation
Variable
Cycle time exceeding 3 minutes (85 seconds neonatal),
power off, or cuff pressure exceeds 290 mmHg (± 6 mmHg)
for adult, 250 mmHg (± 5mmHg) for pediatric, or 150 mmHg
(± 3mmHg) for neonatal
Cuff sizes
Disposable: Large adult, adult, small adult, pediatric, child,
and neonatal
Reusable: Adult thigh, large adult, adult, small adult, small
adult/child, child, and infant
Alarms: User-selectable upper and lower limits for systolic, diastolic,
and mean pressures
